2. Hardware Installation

Now that you have prepared your computer, you are ready to install your

graphics card.

Step 1.

Locate the PCI Express x16 slot. If necessary,

remove the cover from this slot; then align your

graphics card with the PCI Express x16 slot, and

press it in firmly until the card is fully seated.

☛Make sure that the gold edge connector of the graphics card is securely inserted.

Step 2.

Replace the screw to fasten the card in place, and

replace the computer cover.

※ If there are power connectors on your card, remember to

connect the power cable to them, or the system will not

boot. Do not touch the card when it’s operating to prevent

system instability.

Step 3.

Connect the appropriate cable to the card and the display. Finally, turn on

your computer.

DVI-I DVI-D HDMI Mini HDMI

(Dual Link) (Dual Link) Monitor Monitor

D-sub DisplayPort Mini DisplayPort

Monitor Monitor Monitor
