Specifications
Connectivity
SM5KB Series
65SM5KB 55SM5KB 49SM5KB 43SM5KB 32SM5KB
PANEL
Screen Size 65 55 49 43 32
Panel Technology IPS (PD)
Aspect Ratio 16 : 9
Native Resolution 1,920 x 1,080 (FHD)
Brightness 450cd/m
2
400cd/m
2
Contrast Ratio 1,300:1 1,100:1
Dynamic CR 4,000,000:1 2,000,000:1
Viewing Angle (H x V) 178 x 178
Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer (Haze 1 % (Typ.))
Guaranteed Operating Hour
24 Hours
Orientation Portrait & Landscape
CONNECTIVITY
Input HDMI, DP, DVI-D, RGB, Audio, USB 3.0, SD card
Output DP, Audio
External Control RS232C (In/Out), RJ45, IR Receiver, Pixel Sensor
PHYSICAL
SPECIFICATION
Bezel Color Black
Bezel Width
11.9mm (T/R/L), 18mm (B) 11.9mm (T/R/L), 18mm (B) 11.9mm (T/R/L), 18mm (B) 11.9mm (T/R/L), 18mm (B) 13mm (T/R/L), 18mm (B)
Monitor Dimension (W x H x D)
1456.9 x 838 x 56.5mm 1,238 x 714.9 x 54mm 1,102.2 x 638.5 x 54mm 969.6 x 563.9 x 54mm 729.4 x 428.9 x 55.5mm
Weight (Head) 27.9Kg 17.5kg 14.3kg 10.0kg 5.4kg
Weight (Head + Stand) 33.1kg 20.8kg 17.6kg 12.5kg 6.2kg
Monitor with Optional Stand &
Speaker Dimensions (W x H x D)
1,456.9 x 898.1 x
293.7mm
1,238 x 773.4 x
219.6mm
1,102.2 x 696.8 x
219.6mm
969.6 x 622.2 x
193mm
729.4 x 481 x
154.2mm
Carton Dimensions (W x H x D) 1,561 x 977 x 190mm 1,330 x 807 x 170mm 1,197 x 760 x 166mm 1,052 x 650 x 123mm 810 x 510 x 132mm
Packed Weight 33.8Kg 21.7kg 17.4kg 12.6kg 6.7kg
VESA
TM
Standard Mount Interface
300 x 300mm 200 x 200mm
SPECIAL FEATURES
Temperature Sensor, ISM Method, Wi-Fi (802.11n combo built-in), USB Cloning, Contents Scheduling, Sync Mode,
PM Mode, Local Time Auto Setting, Overlay Touch, Wake on LAN, *Pivot Mode, Content Rotation 0,90, Fail Over,
No Signal Image (Up to 5MB), *BEACON On/Off, *Embedded Template
ENVIRONMENTAL
CONDITIONS
Operating Temperature Range 0 °C to 40 °C 0 °C to 40 °C 0 °C to 40 °C 0 °C to 40 °C 0 °C to 40 °C
Operating Humidity Range 10 % to 80 % 10 % to 80 % 10 % to 80 % 10 % to 80 % 10 % to 80 %
POWER
Power Supply 100-240V~, 50/60Hz
Power Type Built-In Power
POWER
CONSUMPTION
Typ. 120W 100W 85W 75W 60W
Smart Enegy Saving 85W 70W 60W 55W 45W
AUDIO POWER 20W(10W x 2) for Internal Speaker (6 ohm)
STANDARD
(CERTIFICATION)
Safety UL / cUL / CB / TUV / KC
EMC FCC Class "A" / CE / KCC
ErP / Energy Star Yes/NA Yes/Yes Yes/Yes Yes/Yes Yes/Yes
MEDIA PLAYER
COMPATIBILITY
OPS Type Compatible Yes
External Media Player Attachable
Yes (MP500/MP700) Yes (MP500/MP700) Yes (MP500/MP700) Yes (MP500/MP700) No
SOFTWARE
COMPATIBILITY
SuperSign-W / Lite Yes
SuperSign-C Yes
ACCESSORY
Basic
Remote Controller (2 batteries included), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
Optional
Stand(ST-652T),
Pixel sensor(KT-SP0),
Media player,
Wall bracket(LSW350B),
VESA Adapter (AM-B330S),
OPS Kit(KT-OPSA),
HDBaseT(EB-B100)
Stand(ST-492T),
Pixel sensor(KT-SP0),
Media player,
Wall bracket(LSW350B),
VESA Adapter (AM-B330S),
OPS Kit(KT-OPSA),
HDBaseT(EB-B100)
Stand(ST-492T),
Pixel sensor(KT-SP0),
Media player,
Wall bracket(LSW350B),
VESA Adapter (AM-B330S),
OPS Kit(KT-OPSA),
HDBaseT(EB-B100)
Stand(ST-432T),
Pixel sensor(KT-SP0),
Media player,
Wall bracket(LSW230B),
VESA Adapter (AM-B220S),
OPS Kit(KT-OPSA),
HDBaseT(EB-B100)
Stand(ST-322T),
Pixel sensor(KT-SP0),
Media player,
Wall bracket(LSW230B),
OPS Kit(KT-OPSA),
HDBaseT(EB-B100)
The SM5KB Series, webOS signage, allows for customized apps that are easy to create
using LG’s Software Development Kit. Its built-in Wi-Fi and SoC reduces the total cost
of ownership and simplifies installation, which allows you to manage content more
conveniently.
➊ SPEAKER OUT
➋ IR & LIGHT SENSOR
➌ PIXEL SENSOR
➍ HDMI
➎ RS-232C IN
➏ RS-232C OUT
➐ AUDIO IN
➑ AUDIO OUT
➒ DVI-D IN
➓ DP IN
DP OUT
RGB IN
LAN
USB 3.0
SD
Smart Platform with a Powerful Embedded System
-
on
-
Chip
Standard Performance SM5KB Series
Screen Defects
Quad Core
Contents Download
App. Execution
Key Features
Smart
Platform
Bezel
11.9mm
Enhanced
Design
Conguration
*SoC : System-on-Chip
55SM5KB / 49SM5KB / 43SM5KB / 32SM5KB
➋ ➌ ➍ ➎ ➏ ➐ ➑
➒ ➓
➊
65SM5KB
➑
➋ ➌ ➎ ➏ ➐➊
➒ ➍➓
Quad Core SoC*
The High Performance SoC can execute several tasks at the
same time and provides smooth content playback.
Slimmer Bezel
The thinner bezel allows a
perfect t for a sleek look.
Detachable Logo
The detachable logo allows
for installation in the desired
orientation in landscape or
portrait mode.
Cable Management
The well-organized cable
terminals in the back
optimize available space.
Built-in IR Receiver
This receiver is very space
efcient with features that are
detachable and adjustable to
suit your environment.
The webOS 2.0 platform provides powerful and convenient tools
to create, including app development materials.
LG may make changes to specifications and product descriptions without notice.
Copyright © 2015 LG Electronics Inc. All rights reserved. “LG Life’s Good” is a registered of LG Corp.
The names of products and brands mentioned here may be the trademarks of their respective owners.
More info www.lgecommercial.com
youtube.com/c/LGECommercialDisplay
Download LG Commercial Display Mobile App
Apple App Store Google Play Store
Built-in Speaker Model (10W x 10W)
Slim
*Pivot Mode, BEACON, Embedded Template : Available after Sept. 2015 rmware update.
