APart KUBO3-BL [21/24] Instruction manual

Instruction manual

KUBO3(T) / KUBO5(T)

model name KUBO5 KUBO5T

loudspeaker system two-way with bass reﬂex

woofer size 5.25”

woofer cone material coated paper

tweeter size 1”

nominal impedance 8 ohms 16 ohms

100V transfo power taps N/A 3W / 6W / 15W / 30W

70V transfo power taps N/A

1.5W / 3W / 7.5W / 15W / 30W

connector wire capacity

(connection and pass-

through)

max. wire size: 2.5 mm² (12 AWG)

frequency range 94 - 20,000 Hz

low impedance dynamic

power

80 W

RMS power 50 W

SPL at 1 W / 1 m 92 92

max SPL at 1m 106 106

dispersion angle (1000 Hz) 180°

IP rating 40

mounting system U-bracket

enclosure ABS plastic

grille main material steel

nearest RAL color code,

colour deviation can occur

black (RAL9011) / white (RAL9016)

net weight 1.7 kg / 5.95 lbs 2.05 kg / 4.52 lbs

dimensions (w x h x d) 164 x 155 x 136 mm / 6.44 x 6.10 x 5.34 inch
