19
The following tips may help you optimize your display:
• Adjust the computer’s graphics card to support a recommended
timing mode (refer to “Specifications” page for recommended
setting specific to your LCD display). To find instructions on
“changing the refresh rate”, please refer to the graphics card’s
user guide.
