Viewsonic VA2403-h [32/60] Specifications
![Viewsonic VA2403-h [32/60] Specifications](/views2/2014229/page32/bg20.png)
28
5. Specifications
LCD Type TFT (Thin Film Transistor), Active Matrix
1920 x 1080 Display,
0.272 mm x 0.272 mm pixel pitch
Display Size Metric: 60 cm
Imperial: 24” (23.6” viewable)
Color Filter RGB vertical stripe
Glass Surface Anti-Glare
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
Separate Sync
DVI (TMDS digital 100ohms)
(for VA2403/VA2403-mhv)
HDMI (TMDS digital 100ohms)
(for VA2403-h/VA2403-mh/VA2403-mhv)
f
h
:24-82 kHz, f
v
:50-75 Hz
Compatibility PC
Macintosh
Up to 1920 x 1080 Non-interlaced
Power Macintosh up to 1920 x 1080
(Supported by limited graphic cards)
Resolution
1
Recommended
Supported
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60, 75 Hz
1280 x 720 @ 60 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 72, 75 Hz
720 x 400 @ 70 Hz
