Figure 4.3 Position A
Position B
6.2) Finish
6.1) Install screws and put screw labels back on.
(Number of screws that hold BEZEL is 12 pieces.
Number of labels is 12 pieces.)
Figure 4.4
F
igure 5.1
F
igure 5.2
Figure 6.1
Figure 6.3
Figure 6.2
Figure 5.3
Figure 5.4
Figure 4.2
4.2) Paste 11 pieces of BRACKET-4 to panel.
NOTE: 1. Adjust the position of BRACKET-4 to the upper hole
in case of POSITION A.
2. Adjust the position of BRACKET-4 to the lower hole in case
of POSITION B.
Figure 4.1
4
.1) Paste TAPE-2 (DOUBLE sided ADHESIVE TAPE) on
B
RACKET-4 and peel off the paper.
(Number of BRACKET-4 is 11 pieces.) Specification of
TAPE-2 should be equivalent to "3M VHB tape 9473".
N
OTE: Do not paste TAPE-2 on the holes.
Adjust the position of BRACKET
PWB IR to the upper hole.
Adjust the position of
BRACKET-4 to the lower hole.
Align edge
Original
Protection glass
1
0 mm
5 mm
5
.1) Paste TAPE-3. Specification of TAPE-3 should be equivalent
t
o "
S
cotchfoam 4718 3,2 / 12,7mm
"
. Ideal Size: 5mm (H) X 10mm
(W) (Fig. 5.2) NOTE: Align the edges of the panel and the glass
(refer to Fig.5.1). 2.Carefully move the BRACKET PWB IR as in
F
ig. 5.3, when pasting TAPE-3.
Paste TAPE-2 on this area
B
RACKET-4
T
APE-2
A
A
A
A
A
A
B A
A AA
P
eel paper off after pasting TAPE-2
TAPE-3
