1.1) Lay LCD on a mat as in Fig.1 (in order not to damage LCD).

1.2) Remove STAND

(if used) and BEZEL

(Number of screws

that hold the STAND

is 2 pieces.

Number of screws

that hold the BEZEL

is 12 pieces.)

3.2) Put protective glass on the panel.

NOTE: Align edge (refer to Fig. 3.4).

3.3) Reinstall the BRACKET PWB IR and rear cover.

(Number of screws that hold the rear cover is 3 pieces.)

NOTE: Adjust the position of BRACKET PWB IR to the

lower hole.

Figure 3.1

Figure 3.2

Figure 3.3

Figure 3.5

Figure 3.4

Align edge

60mm

2.1) Remove the part of the rear cover indicated in figure 2.1 and

the BRACKET PWB IR. (Number of the screws that hold the

rear cover is 3 pieces.)

3.1) Paste TAPE-1 (DOUBLE sided ADHESIVE TAPE) and peel

the paper off. Specification of TAPE-1 should be equivalent

to "3M VHB tape 9473".

NOTE: 1. Do not paste TAPE-1 on panel's active area.

2. Do not paste TAPE-1 on the area in Fig. 3.2.

Figure 1

Figure 2.1

Figure 2.2

Adjust the position of BRACKET

PWB IR to the lower hole.

Remove BRACKET PWB IR

rear cover

Remove the three screws

Paste TAPE-1 on this area

Do not paste TAPE-1

on this area. This note

refers to all 4 corners.

BRACKET PWB IR

INSTALLATION MANUAL

PROTECTIVE GLASS

FOR MULTISYNC

LCD4020,

LCD4620 AND LCD5220

NECESSARY COMPONENTS:

- 1 piece protective glas (supplied)

- brackets (supplied) (40"-11pcs, 46"-13pcs, 52"-12 pcs)

- tape, "3M VHB tape 9473" or equivalent (not supplied)

- tape, "Scotchfoam 4718 3,2/12,7mm" or equivalent (not supplied)

Product used for demonstration in this manual: LCD4020
