GHP40-2水泵机组配置表
55
3S12081 flange nut M8 8
56
3S12061 flange nut M6 2
57
3S11101 nut M10 4
58
3S21100401 bolt M10X40 4
59
3G20010 240F high pressure washer flange 1
60
3S22080351 flange bolt M8X35 4
61
3S22080121 flange bolt M8X12 4
62
3G20033 390 pump prop 2
15
3G4040047 porcelain seal 1
16
3G4040039 O ring 1
17
3G4040037 block ring 1
18
3G4040036 shaft 1
19
3G4040033 volute casing 1
20
3G4040031 impeller discreteness 1
21
3G4040034 O ring 1
22
3G4040032 sleeve 1
23
3G4040035 volute casing 1
24
3S3610126
gasket φ10
1
25
3G4040029
gasket φ10
1
26
3S21100161 bolt M10X16 1
27
3G4040026 volute basing cover 1
28
3S27050162 bolt 1
29
3G4040015 inpact block 1
30
3G4040024 check discretness 1
31
3G4040027 volute casing plastic seal gasket 1
32
3S22080351 flange bolt M8X35 8
33
3G4040021 gasket φ88
34
3G4040023 square screw cap 1
35
3G4040014 pump body 1
36
3G4040011 seal gasket 1
37
3G4040004 outlet bracket 1
38
3G4040005 outlet cover II 2
39
3G4040008 seal gasket II 2
40
3S22080601 flange bolt M8X60 4
41
3G4040002 water input cover 1
42
3G4040003 O-ring 1
43
3G4040006 hose connector II 2
44
3G4040007 hose ringer II 2
45
3G4040042 hose clamp II 2
46
3G4040009 outlet cover II 2
47
3G4040010 seal gasket I 2
48
3G4040012 hose connector I 2
49
3G4040013 hose ringer I 2
50
3G4040041 hose clamp I 3
51
3G4040043 filter net 1
52
3S22080201 flange bolt M8X20 4
53
3G20011 shock absorber 4
54
3JGH4020001 frame 1
