Lens Unit User’s Manual

Model NP30ZL

This manual discusses speciﬁcations and focus adjustment for the NP30ZL short focus zoom lens.

For cautions on handling the lens, see the User’s Manual supplied with the lens.

For instructions on mounting, removing, and cleaning the lens, see the User’s Manual supplied with the projector.

NOTE: The drawings in this manual may differ slightly from the actual product.

Speciﬁcations

Throw distance (Unit: m)

Projector model name

Screen size (inch) PA600X/PA500X PA550W PA500U

30” - - -

40” - - -

60” 1.0-1.3 1.0-1.3 1.0-1.3

80” 1.3-1.7 1.4-1.8 1.4-1.8

100” 1.6-2.1 1.7-2.2 1.7-2.2

120” 2.0-2.6 2.1-2.7 2.0-2.7

150” 2.5-3.2 2.6-3.4 2.6-3.4

200” 3.3-4.3 3.5-4.5 3.4-4.5

240” 4.0-5.2 4.2-5.5 4.1-5.4

300” 5.0-6.5 5.3-6.8 5.2-6.8

400” 6.7-8.7 7.0-9.1 6.9-9.0

500” 8.4-10.9 8.8-11.4 8.7-11.3

TIP:

Calculation of the throw distance from the screen size (m)

PA600X/PA500X: H x 0.8 to H x 1.1 : 1.0 m (min.) to 10.9 m (max.)

PA550W: H x 0.8 to H x 1.0 : 1.0 m (min.) to 11.4 m (max.)

PA500U: H x 0.8 to H x 1.0 : 1.0 m (min.) to 11.3 m (max.)

* “H” (Horizontal) refers to the screen width.

* Figures differ by several % with the table above because the calculation is approximate.

Lens shifting range

The lens shift dials on the projector allow you to move the position of the projected image in the vertical and horizontal

directions based on the following ranges.

Description of symbols: V indicates vertical (height of the projected image), H indicates horizontal (width of the pro-

jected image).

For adjusting the lens shift, see the User’s Manual supplied with the projector.
