Levenhuk Femto Polar 77983 [5/40] Specifications

5

centered when the objective is changed to a more powerful one. Once the segment is selected, you should center its

image in the microscope’s field of view as precisely as possible. Otherwise, the desired segment might fail to center

in the field of view of the higher power objective. Now, you can switch to a more powerful objective by rotating the

revolving nosepiece. Adjust the image focus if required.

Digital camera (for the digital model only)

The digital camera is installed in the eyepiece tube in place of the eyepiece. It allows to observe specimens in fine

detail and true colors on your PC monitor and save images on the hard drive. The soware allows viewing and

editing the object images.

7.5@1280x1024

Video recording +

Image format *.jpg, *.bmp, *.png, *.tif

Video format *.wmv, *.avi

Exposure ERS

Interface USB 2.0, 480Mbit/s

System requirements

Windows XP (32-bit), Vista/7/8/10 (32-bit or 64-bit), Mac OS X, Linux,

CPU IntelCore 2 or above, RAM 2GB, USB port 2.0, CD-ROM

Specifications

Optics material optical glass optical glass

Body material metal metal

Eyepiece tube diameter, mm 23.2 23.2

Eyepieces WF10x WF10x

Revolving nosepiece 3 objectives 3 objectives

Objectives achromatic: 4x, 10x, 40xs achromatic: 4x, 10x, 40xs

Stage, mm 90x90, with specimen holders 90x90, with specimen holders

Stage moving range, mm 0—10, vertical 0—10, vertical

Focusing

coaxial, coarse (0.5mm) and fine

coaxial, coarse (0.5mm) and fine

3*АА batteries or 110—240V,

via AC adapter

3*АА batteries or 110—240V,

via AC adapter

Digital camera — 3 megapixels

The manufacturer reserves the right to make changes to the product range and specifications without prior notice

Note: Batteries might be pre-installed in the battery compartment by the manufacturer.
