7
EN DEVICE EXTERIOR (see page 2–3)
SPECIFICATIONS
Connection: BT (5.0, up to 10 m, −30...−20 dBm, 0.001–0.01 mW) and USB
Type-A/Type-C cable.
Battery: non-removable, lithium polymer, 600 mAh, run time up to 8 h, charging time 2 h,
via USB Type-C connector ⑪ (power supply output: 5 V / 500 mA DC).
Operating and storage conditions: temperature −10...+45 °C, relative humidity up to
55 % (non-condensing).
Design features: 152×102×60.5 mm, 200 g, plastic.
Functional features: 16 buttons, 2 built-in vibration motors, backlit buttons A, B, X, Y ⑥
and right joystick ⑨.
Scope of supply: LRG-GP510 gamepad, USB cable Type-A/Type-C (1 m), BT
transmitter, quick start guide.
Purpose: gamepad for wired and wireless connection to devices with iOS 13.0 and
above, Android 4.0 and above, Nintendo Switch, PS3, Windows 7 and above. Wired
connection to Android is only available for OTG-enabled devices using the OTG adapter
(not included). Wired connection to iOS is not supported.
SAFE USE GUIDELINES
Read and follow these instructions before using the device.
Do not expose the device to high temperatures (from heaters, direct sunlight), high
humidity, keep the device away from dust and liquids.
Clean the device only after disconnecting it from the power supply, use only a dry cloth
for cleaning, do not use detergents, cleaning agents or solvents. Do not use a device
that is heavily contaminated, defective, or overheated.
Do not disassemble or attempt to repair the device yourself. If it breaks, contact the
service center.
If the battery is damaged or leaking, do not use the gamepad or touch the gamepad,
battery, or leaking fluid.
GAMEPAD USE
1. Charging. Fully charge the battery before using it for the first time. Connect the USB
cable to the USB Type-C connector ⑪ of the gamepad and to a power source: a device
that supports the USB charging function or a wall charger (not included). The gamepad
also charges while wired to PCs and consoles. The indicator ⑫ will light red while
charging is in progress.
2. Switching on the gamepad. Hold the X button ⑥ and press and hold the Home
button ④ until the LED indicators ⑧ and the backlight of the right joystick ⑨ light up.
3. Connecting the gamepad to devices.
① Left joystick ⑨ Backlit right joystick
② Back button ⑩ LT – left trigger, RT – right trigger
③ Turbo button ⑪ USB Type-C connector
④ Home button ⑫ Charging indicator
⑤ Start button ⑬
LB – left bumper button,
RB – right bumper button
⑥ Backlit buttons A, B, X, Y
⑦ D-pad: 8-way control button ⑭
BT transmitter
⑧ LED indicators ⑮ Reset button
