Instruction Manual
4
Maintenance and care
The outside of the appliance can be
cleaned with a slightly damp cloth.
Accessories
1 pc
Specifications
Specifications and functions are subject to change without notice. It is connected with continual
improvement of the device.
MANUFACTURED AND DISTRIBUTED BY TECHNO ELECTRIC LIMITED,
Legal address: 801 Luk Yu Building, 24 - 26 Stanley Street, Central, China
Radio
Power cord
Instruction manual
1 pc
Bluetooth
The Bluetooth pairing name of the unit is
SM-RD2123UB.
Press the MODE button to select
the Bluetooth mode.
Use your mobile device to search the
Bluetooth signal of the unit, then input the
password 0000 if necessary.
Switch off the Bluetooth function on your
mobile device to disconnect the units. When
paired successfully for the first time, this unit
will automatically connect the paired device
when it switches on.
Effective connection range is 10 meters in
direct line of sight.
You can control playback and volume
using the standard control elements of this
unit.
FAT and FAT32 file system is supported
by this unit.
Never remove microSD cards and USB
drives from the unit during playback,
always stop playback, then switch to
another mode before removing the
storage to prevent damage to your
files and cards/drives themselves.
Nominal power consumption
5 W
Radio frequency range
FM 64  108 MHz
AM 5301605 kHz
SW 8 – 16 MHz
Built-in Li-ion battery
3.7V; 1800 mAh
Net weight
0.989 kg
Unit dimensions
23 * 12 * 75 cm
Power output
2*2 W
Mains power
~220V; 50-60 Hz
Battery power
type D (UM-1) * 3 pcs.
AUX input
You can output sound from an external
audio device through the speaker of this
radio by connecting an external device to the
AUX IN audio input.
To connect an external device, use a
standard cable with 3.5 mm plugs to
connect the line out or headphone out jack
to the 3.5 mm AUX IN jack on the side of
the radio.
Turn on the external device. You cannot
control playback with the buttons of this unit
except adjusting the volume.
1 pc
