Asus Vivobook Pro 15 OLED M3500QC-L1301W [22/96] Right view

Notebook PC E-Manual

Right View

Headphone/Headset/Microphone jack

This port allows you to connect amplied speakers or

headphones. You can also use this port to connect your headset

or an external microphone.

MicroSD card slot

This built-in memory card reader slot supports microSD card

formats.

Intel model

AMD model
