004

2. AORUS Notebook Tour

DCIN

11109 14

DCIN

15 18 1916 17

1 Display Panel 11 USB 3.2 Port (USB type-A )

2 Webcam Cover 12 Microphone Input Jack Port

3 Webcam 13 Headphone Output Jack Port

4 Microphone 14 USB 3.2 Port (USB type-A )

5 Power Button 15 USB 3.2 Port (USB type-A )

6 Keyboard 16 Thunderbolt 4 Port (USB type-C)*

7 Fingerprint Sensor 17 Mini Display 1.4 Port

8 Touchpad 18 HDMI 2.1 Port



9 Ethernet Port (LAN) 19

Power Input Port (DC)

10 SD Card reader (UHS-II)* 20

Speaker

Option

IMPORTANT:

● Do not remove the built-in lithium battery.

For any service needs, please contact your local GIGABYTE Authorized Service Center.

● Do not install the Notebook PC on a slant or a place prone to vibrations, or avoid using the Notebook PC in

that location for

a long time.This increases the risk that a malfunction or damage to the product will occur.

● Do not store and use Notebook PC in direct sunlight or the location where temperatures exceed 112°F (45°C)

such

as inside a vehicle.There is a danger of Lithium-ion battery expansion and aging.

● Do not use the Notebook PC in a badly ventilated location such as on bedding, on a pillow or cushion, etc,

and do not use it in a location such as room with floor heating as it may cause the computer to overheat.Take

care that the Notebook PC vents (on the side or the bottom) are not blocked especially in these environments.

If the vents are blocked, it may be dangerous and cause the Notebook PC to overheat.
