Sven SRP-505, черный [4/16] Portable radio

ENG

Portable Radio

i Micro SD card slot

j AUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)

k Player indicator

l Battery charge process indicator

m DC 5V: micro USB jack for charger connecting radio to laptop/PC USB port

CONNECTION AND OPERATION

Attention! The built-in battery must be charged completely prior to the application.

Battery charging

• Connect radio to a USB port of PC or USB charger using micro USB to USB cable

(included). During battery charging the indicator l is red. Indicator l goes out when the

battery is charged.

• The battery is used in the radio as an integral part of the device, therefore do not try

to extract or replace it, because this can result in the warranty cancellation or the device

damage.

OPERATION MODES

Bluetooth mode

• Wireless data transfer via the Bluetooth protocol enables to connect radio to compatible

devises. Maximum radius of action of data transfer is 10 m. Such obstacles as walls or

other electronic devices can interfere with the signal transfer.

• Turn on the radio and select Bluetooth mode. To do this, move the mode selection knob

f to the highest position. If necessary (switching from USB/microSD), additionally press

the MODE c button on the front panel, a sound confirmation of the selected mode will

be heard.

• It is necessary to select the search mode of devices with Bluetooth on a signal source

(telephone, notebook, smartphone, etc.). «SVEN SRP-500/SRP-505» massage will be

displayed on the screen which is to be connected to*.

• When connection is successful, there will be a short beep**.

Player mode

Attention! The file system of a micro SD carrier is FAT32. Maximum volume is 32 GB. It is

not recommended to use the micro SD Ultra Speed.

• Insert the USB flash or micro SD carrier into appropriate slot, if the radio is in turned

on position and MUSIC mode is on, the playback will start automatically. Playback/Pause

modes are switched over with the help of the button d. Tracks can be controlled by

buttons a (previous track) and b (next track).

* You might have to enter «0000» code to connect some models of devices via Bluetooth.

** If the item has been already registered in the device list of a source, then the second

search mode activation is not obligatory. Choose the item name «SVEN SRP-500/SRP-505»

and the «connect» command on the source.
