6 7
ELEMENTS OF DESIGN, Рiс. B-2
1
2
3
4
Feeding chute
Switch
Handle
Rubberized feet
UTILIZATION
Control panel, Рiс. B-2-2
ON/OFF switch.
Position of switch:
«ON» – power ON;
«OFF» – power OFF.
Before rst use, wipe the body of the device with a
soft, dry cloth. The rest of the parts wash with warm
water and detergent. Dry. Wipe with a dry clean cloth.
Before assembling or disassembling the device
and / or removing nozzles, make sure that the de-
vice is unplugged.
Assembling order, Рiс. С
1. Place the base on a at and stable surface. Tilt the
cutting unit
9
slightly to the right and insert it into the
multislicer by turning it counterclockwise until it clicks
into place, Pic. С-1.
2. Select the required shredder/grater, Pic. D-3.
3. Place the shredder or grater inside the cutting unit
9
Pic. C-2. Rotate the shredder/grater slightly so that
the pentagonal hole on it aligns with the shape inside
the cutting block.
4. Secure the shredder/grater with the lock
3
by turn-
ing it counterclockwise, Pic. C-3.
NOTE: To change the shredder/grater, unlock it by turn-
ing the lock
3
clockwise, Pic. C-4. Replace the shred-
der/grater and secure it again with the lock
3
.
When installing/changing the shredder/grater,
hold the plastic part, do not touch the sharp
knives.
Order of operation:
1. Assemble the device as indicated in the previous
section, Pic. C.
2. Plug in the device. Place a suitable container under
the outlet of the cutting unit
9
.
3. Using the pusher, place pre-washed and, if neces-
sary, cleaned and chopped ingredients into the feed
chute, Pic. D-1.
4. Turn on the device by pressing the switch “ON posi-
tion”, Pic. D-2.
5. At the end of operation, turn o󰀨 the device by press-
ing the switch “Position -OFF” and unplug the device.
The maximum allowable time of continuous
use of the device is 2 minutes.
The break between cycles should be 5
minutes. After 5 cycles, the break should be
25-30 minutes.
Do not grind the ingredients which
temperature is higher than 80°С. Let them
cool.
Operation name Ingredients Note
Grater for straws (large / small)
6
,
7
Preparing salads, appetizers, preparing
vegetables for soups and main courses,
chopping cheese and boiled eggs.
Cut the initial ingredients into pieces (carrots,
zucchini, peppers, potatoes, hard cheese, chocolate)
so that they freely pass through the feed chute, press
them with a pusher to the grater.
Let the boiled vegetables
cool completely before
grating them.
Slicing (thin/thick)
4
,
5
Preparing salads, appetizers, preparing
vegetables for soups and main courses,
slicing.
The ingredients should be dense (cucumbers,
radishes, peppers, fresh potatoes, carrots,
zucchini, cabbage, etc., smoked sausages, hard
cheeses, etc.). Pre-cut them into portions so that
they freely pass through the feed chute. Push the
ingredients with the pusher, pressing them lightly.
Store sausages and
cheese in the refrigerator
before slicing.
Grater (for puree)
8
Preparation of baby food, grinding to a
gruel/powder state, grating products.
Prepare the initial ingredients (hazelnuts, walnuts,
dry bread, garlic, zest) cut them if necessary
(hard cheese, chocolate). Push the ingredients
with the pusher, pressing them lightly.
Possible problems Possible causes Solutions
Device doesn’t turn on. There is no voltage in the socket. Unplug the device and wait until the voltage
normalizes.
Device stopped working The motor overheating protection may
have tripped.
Unplug the device from the power supply and
let it cool down for 15-20 minutes. Then plugin
the device and turn it on. If the problem persists,
contact an authorized OURSSON service center.
The device began to work
slowly
Perhaps a hard piece is stuck. Turn o󰀨 the device, unplug it. Remove the
attachment lock and remove it from the cutting
unit. Remove the stuck pieces of the product.
CLEANING AND MAINTENANCE, Рiс. D
• Clean all the parts of the device immediately
after use.
• Switch o󰀨 the device. Unplug it.
• Remove the pusher from the feed chute.
• Make sure that the moving parts have stopped.
Then disconnect the shredder/grater by turning the
lock clockwise, Pic. C-4. Remove the shredder/
grater from the cutting unit and detach the cutting
unit from the body by tilting it slightly to the right,
Pic. C-5.
• All removable elements can be washed in warm
water using non-abrasive detergents. They cannot
be washed in the dishwasher
• Wipe the motor unit with a soft damp cloth. Never
immerse the motor unit in water due to the danger
of electric shock.
• Dry all parts of the device thoroughly and store
in a dry and clean place.
PRODUCT CERTIFICATION
For information on product certication, see http://www.oursson.com or ask seller for a copy.
Only a qualied specialist from OURSSON AG service center must do the repair.
PREPARATION RECOMMENDATIONS
Before grinding, it is recommended that the ingredients be washed/cleaned and cut into pieces.
POSSIBLE PROBLEMS AND SOLUTIONS
SPECIFICATIONS
Model MS2050
Power consumption, W max 150
Rated voltage 220-240 V~; 50-60 Hz
Protection class II
Storage and transportation temperature -25°C tо +35°C
Operation temperature +5°C tо +35°C
Humidity Requirements 15-75% without condensation
Size of the device, mm 280х199х106
Weight, kg 1,48
*Products must be stored in dry, ventilated warehouses at a temperature not lower than -25°С.
