USERʼS MANUAL
Product Features
• Cree XP-L HI and XP-G3 LEDs
• Neutral light, close to sunlight (4200К)
• Max output 1100 lm
• Separated throw and wide light with a number
of options to combine it
• 4 basic brightness modes for each of LEDs
• 24 options for basic light of different brightness
and light distribution
• Memory of brightness modes for throw and wide
light separately
• Additional hidden Minimum mode
• Fast access to Max thrower and Turbo from
any mode or switched off flashlight
• Package includes protected Li-Ion 18650
Samsung 26J 2600 mAh battery with USB-charger
• Battery discharge indication, battery level check
• Integrated thermal sensor to avoid
the overheating
• Removable magnet on a side
• Waterproof IPX8
Battery charge level
Red color battery discharge indicator LEDs in the
buttons turns on when the battery is low.
To check the battery level make three short clicks
on the grey button when the flashlight is OFF. The
flashlight blinks from 1 to 5 times depending on
battery charge status.
To avoid the overdischarge the flashlight turns OFF
when the voltage is low.
It is recommended to change or recharge the
battery after.
If it is necessarily to continue work after tipping
event with using the same battery – unscrew the
battery case cap for several seconds, screw it back,
and turn ON the flashlight in minimum mode with
holding the right (grey) button.
Thermal control
Moderate heating of the flashlight is normal while
working in upper modes and it is necessarily for heat
removal. To avoid the overheating, maximum
brightness will be decreased to 50% by integrated
thermal sensor.
Specifications
Flashlight is powered by one 18650 Li-ion battery,
permitted voltage 3.0 - 4.2 V, acceptable length
65-70 mm. It is recommended to use high-quality
protected batteries from reliable suppliers.
Using 2xCR123A batteries or 2xRCR123 batteries is
forbidden!
OPERATING
Right one (grey color) button is used for turning
ON/OFF the flashlight and for changing the bright-
ness.
Left one (black color) button is used for changing
between wide, throw and combined light and for
fast access to Maximum modes.
Basic operations
To turn ON/OFF the flashlight – press the grey button.
The flashlight turns on in memorized mode.
To change the mode – press and hold the grey
button, the modes changes in circle Low – Med –
High – Maximum. The chosen mode is stored in
memory for each LED separately.
To change between wide, throw and combined
light press the black button. The chosen type of the
light is stored in memory.
To equalize the brightness of two LEDs (bringing
them to the same brightness mode), set the com-
bined light type and start cycling changing of
modes with holding the right (grey) button.
Additional operations
For fast access to Maximum thrower – press and
hold the black button. To get back to the previous
state click the black button.
For fast access to Turbo mode – double-click the
black button. To get back to the previous state click
the black button.
To turn ON the flashlight in minimum mode – press
and hold the grey button. The flashlight turns on in
memorized light type with minimal brightness. Mini-
mum modes aren’t stored in memory and don’t
change the modes memory settings.
www.YLPlight.com
The memory of brightness modes (one/two LEDs):
Minimum (hidden) – 10 / 20 lm, 150 / 75 hours
Low – 35 / 70 lm, 36 / 18 hours
Med – 120 / 240 lm, 10 / 5 hours
High – 240 / 480 lm, 5 / 2.5 hours
Maximum – 550 /1100 lm, thermal control
2 years warranty.
Ocean Allied Global Limited, Office 3A-7, 12F, Kaiser
Centre, No. 18 Centre str., Sai Ying Pun, Hong Kong.
Made in P.R.C.
Warranty
Package includes
1. Headlamp
2. Headband with detachable top strap
3. Li-Ion 18650 Samsung 26J 2600 mAh battery
with USB-charger
4. User manual
Compact headlamp powered by one
18650 Li-Ion battery with throw and wide
light.
