USERʼS MANUAL
Product Features
• Adjustable focus
• Neutral light closely resembling sunny (4200К)
• Powerful Cree XP-L HI
• High-quality focused light, without «tunnel effect»
• 322 m beam distance (ANSI)
• 800 lm max power LED light
• Three modes of brightness: 100%, 30%, 5%
• Programmable modes order
• Comfortable side button switch
• Integrated micro-USB charger
• Protected Li-Ion battery 18650 (included)
Guidance and modes
Setting serial mode
Three lines of modes are implemented in the flash-
light:
1) 100% – 30% – 5% (default), 2) 30% – 5% – 100%, 3)
5% – 30% – 100%. To change the line please turn on
the flashlight, then press the button for 7 seconds.
After the flashlight will flash to indicate a change of
line mode. One blink is set the line 1, two blinks – line
2, three blinks – line 3 accordingly.
USB-rechargeable
Integrated charger works with the standard
micro-USB port that is secure against dripping and
splashing water while using the flashlight. To get to
the charging connector you need to twist the head
and the curtain, hiding the connector, smoothly
rushes into the case.
Choice of batteries
18650 Li-Ion battery of increased capacity (length is
65-70 mm ). We recommend to use high-quality
protected batteries produced by approved manu-
factures.
Use of 2 pcs CR 123 and 16340 battery is not accept-
able.
Unscrew the back cover to install the battery. Bat-
tery should be placed by "plus" part to the torch
head.
To prevent accidental pressing please unscrew the
back cover of the torch by 1/4 part.
Universal flashlight with adjustable focus
and integrated charger
www.YLPlight.com
2 years warranty.
Ocean Allied Global Limited, Office 3A-7, 12F, Kaiser
Centre, No. 18 Centre str., Sai Ying Pun, Hong Kong.
Made in P.R.C.
Warranty
Three modes of brightness allow to choose neces-
sary luminous intensity and time of operation of the
torch. Modes of brightness are realized without
low-frequency PWM-blinking that makes work in
difficult weather conditions easier and decrease
visual fatigue. Order of modes is programmed, you
can choose any of modes as starting.
Three modes of brightness:
maximum – 800 lm (100%), 1.5 hours;
medium – 240 lm (30%), 7 hours;
low – 40 lm (5%), 44 hours.
Convenient side button gives the possibility choose
necessary mode of brightness, change torch
settings as well as send signals by partial pressings
without fixing.
Light (without click) pressing button makes the torch
switched on. This mode is for signaling. To switch
100% mode you should press the button until its
clicking position. To change the modes use half
pressing (without click). Subsequent modes change
100% – 30% – 5%. To switch off the flashlight press the
button until its clicking position.
