Deerma DEM-CF10W [2/6] Circuit diagram
![Deerma DEM-CF10W [2/6] Circuit diagram](/views2/2024364/page2/bg2.png)
Precautions
Product Structure
(Note: The above product picture is for reference only, and the
appearance and colors are subject to the actual product.)
Cool air switch
3
1
Magnetic nozzle
Air inlet
2
4
Mode switch
Product name:Hair Dryer
Product model:DEM-CF10W
Rated voltage:220-240V~
Rated frequency:50-60Hz
Rated power:1600W
Product Parameters
● WARNING: Do not use this appliance near bathtubs,
showers, basins or other vessels containing water.
● Always unplug this product after use in the bathroom,
because even after this product is switched off, there is
still a danger near water.
● When installing and fixing the hair dryer, ensure that it
cannot be touched during bathing or showering if its
hand-held part is completely straightened,
● Do not insert metal objects into the air inlet and
outlet to avoid electric shock, and do not block the air
inlet and outlet.
● Before powering on the product, please make sure
that the voltage marked on the product is consistent with
the local power supply voltage.
● Do not use this product for any purpose other than
those described in this manual, and do not use this
product for wigs.
● When the product is powered on, do not leave it
unattended, and be sure to unplug the product after use.
● Do not allow persons (including children) who are
incapacitated or suffering sensory processing disorder
and mental illness or lacking relevant experience and
knowledge to use or play with this product.
● Do not use any accessories or parts produced by
other manufacturers or not specially recommended; if the
use of such accessories causes any quality problem of
the product, your warranty will be invalidated.
● If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
● In order to increase the protection, it is recommended
to install a residual current device (RCD) with a rated
residual working current not exceeding 30mA in the
electrical circuit of the bathroom. Please consult the RCD
installer.
● If the product overheats, it will be automatically
powered off. Then unplug the product and let it cool for
a few minutes. Before powering on the product again,
please check the air inlet and outlet to ensure that they
are not blocked by lint, hair and other debris.
● A peculiar smell may appear in the first use, which is
caused by the lubricating oil used in the heating wire of
the new product, and can be eliminated after 2~3 normal
uses.
● Keep the product dry during use; do not touch the
front air outlet and rear air inlet with fingers or other
metal parts.
2
1
3
4
This diagram is only for reference, and is subject to
update without notice.Please refer to the actual product.
Deerma reserves the right to final interpretation.
Circuit Diagram
Do not use this device in a bathtub, shower,
or water-filled reservoir.
