ted to the charger.
INSTRUCTIONS FOR USE
USE:
- Turn the appliance on, by using the on/o󰀨
switch. (B)
- The ON indicator lamp will light up. (C )
- Select the desired power.
- Slide one position for ECO speed / slide two
position for TURBO speed.
- To use the hand vacuum:
- Press the hand vacuum extraction button (H) on
the brush vacuum’s main body (E). (Fig. 2)
- Turn the appliance on, by using the on/o󰀨
switch. (I)
INSERTING THE MOP
(*) Only on the Inedit 29.6 Wash model
- Fill the mop’s water tank with water and, if ne-
cessary, add a few drops of detergent.
- Attach the water tank to the back the vacuum
cleaner’s brush base so that it clicks into posi-
tion and press the button to open the passage
for the water (Fig.3b)
- The mop can also be used dry.
- NOTE: The mop is machine washable.
FITTING AN ACCESSORY TO THE HAND
VACUUM:
- Press the hand vacuum extraction button (H) on
the brush vacuum’s main body (E). (Fig. 2)
- The hand vacuum is designed in such a way
that it allows the following accessories to be
tted: (use the combination that best meets your
requirements). (Fig.3)
- Furniture brush: Equipped with a brush at the
end, which brushes the surface as it is used.
- Crevice nozzle: Specially designed for getting
into cracks and di󰀩cult corners.
PARKING POSITION:
- This appliance has one parking position for
comfortable and straightforward storage.
FOLDING HANDLE:
- This appliance has a folded handle position for
easy storage. (Fig.4)
CLEANING
- Disconnect the charger from the mains and let it
cool before undertaking any cleaning task.
- Clean the appliance using a damp cloth with a
few drops of detergent and then dry it.
- Do not use solvents, or products with an acid or
base pH such as bleach, or abrasive products,
for cleaning the appliance.
- Do not submerge the appliance in water or any
other liquid, or place it under a running tap.
EMPTYING THE DUST BOX:
- Empty the vacuum deposit when dust is visible
though the transparent walls, when it is full, or
when the vacuum cleaner does not work to its
full potential.
- Press the hand vacuum extraction button (H) on
the brush vacuum’s main body (E). (Fig. 2)
- Disconnect the dust box from the appliance.
(Fig. 5)
- Remove the cloth lter and its protector. (Fig. 6)
- Empty the contents into a suitable rubbish
container.
- Clean the dust box lter.
- Attach the dust box to the appliance.
- To reassemble, follow the above instructions but
in reverse.
CHANGING THE FILTERS:
TO REMOVE FILTERS:
- Press the hand vacuum extraction button (H) on
the brush vacuum’s main body (E). (Fig. 2)
- Disconnect the dust box from the appliance.
(Fig 5)
- Remove the cloth lter and its protector. (Fig. 6)
- To reassemble the lter, proceed with the above
instructions, in reverse order.
- Cleaning the rotary brush:
TO REMOVE THE BRUSH:
- Turn the rotating button on the bottom of the
tting to the left in order to release the brush.
(Fig. 7)
- Remove the brush and clean.
- To reassemble, follow the above instructions but
in reverse.
SUPPLIES
- Supplies can be acquired from distributors and
authorised establishments (such as lters, etc. )
for your appliance model.
- Always use original supplies, designed speci-
cally for your appliance model.
HOW TO REMOVE THE BATTERIES FROM
THE INTERIOR OF THE DEVICE:
- Caution: It is important that the batteries are
fully discharged prior to its withdrawal from the
