Brightness modes
2 years warranty.
Ocean Allied Global Limited, Office 3A-7, 12F, Kaiser
Centre, No. 18 Centre str., Sai Ying Pun, Hong Kong.
Made in P.R.C.
Warranty
Turbo - 1200 lm, 1.5 h*
High – 450 lm, 2.5h
Med - 130 lm, 9 h
Low – 25 lm, 45 h
Moonlight - 1 lm, 50 days
Stroboscope
* depending on the brightness changes because
of the thermal regulation
Weight: 79 g (without battery).
Dimensions: length 109 mm, head diameter 27 mm,
body diameter 24 мм.
Operating
To turn ON the flashlight in the memorized mode
press the button. To change the mode – press and
hold the button, the modes changes in circle Low –
Med – High. The chosen mode is stored in memory.
It is possible to start with Turbo and Moonlight
modes independently from memorized mode. To
activate Turbo mode twice quickly click on the
button; to activate Moonlight mode press and hold
the button. Activated this way, modes doesn’t
stored in memory, the regular switching ON the
flashlight will activate the main memorized bright-
ness mode.
To activate Turbo mode when the flashlight is ON –
twice quickly click on the button. Repeating twice
clicking will activate the previous mode.
To activate Stroboscope triple press for the button.
The flashlight emits a lot of heat in High mode. To
avoid the overheating, maximum brightness can be
decreased by integrated thermal sensor.
To avoid accidental switching on – untwist the tail-
cap 1/4 turn. According to high power of the flash-
light, it is highly recommended to lockout it during
the transportation.
Battery indication
Battery indicator in the button blinks 1-5 times de-
pends of the battery level after start in any basic
mode. If the battery lewel is low, indication LEDs will
constantly idicate it by double blinking. It is recom-
mended to step down to lower modes and replace
or recharge the battery as soon as possible.
Customizable operations
G18 is completely ready for use “out of the box”,
but you can also customize the functions you want.
For example, it is possible to change the number or
brightness of modes, to turn memory off, etc.
The extended manual
is available on web.
ylplight.com/faq29/gryphon-g18-um/
If you accidentally change the settings of the G18
and you want to cancel the changes, press the
button 12 times – and the headlamp will be reset to
the default settings.
www.YLPlight.com
Selecting and installing batteries
Flashlight is powered by one 18650 Li-ion battery. It is
recommended to use high-quality protected bat-
teries from reliable suppliers, recommended capac-
ity 2600 mAh and more.
To install the battery unscrew tailcap, insert the
battery into the flashlight with the positive contact
forward, twist the tailcap until tight.
Charge the battery fully before the first use. Con-
nect the flashlight to a USB adapter (recommended
1A or more). Charging process is indicated by red
indicator LED in the button.
Package includes
1. Flashlight
2. Clip
3. Lanyard
4. Protected Li-Ion 18650 battery 2600 mAh
USERʼS MANUAL
Product Features
• 3 Samsung LH351D High-CRI LED
• Neutral light, close to sunlight (4000К)
• Color rendering >90CRI
• Beam distance up to 110 m according to ANSI
standard
• Max output 1200 lm
• Five brightness modes: from 1 to 1200 lm
• Additional Strobe mode
• The memory of the modes
• Fast access to Turbo and Moonlight modes
• Customizable user interface
• Battery level indication
• Built-in thermal control
• Convenient side button
• High quality Carclo optics (TIR)
• Waterproof IPX8
Powerful compact multipurpose flashlight
with neutral white High-CRI light and inte-
grated charger. Powered by one 18650
Li-ion battery.
