Topdevice Tablet C8 TDT4528_4G_E_CIS [6/24] Operating instructions

Tablet

Topdevice

EN General info

Specifications

Display: 8", IPS, 800×1280. Operating system: Android

11.

Multi

touch: yes. RAM: 3 GB. Built-in memory: 32 GB. Supports memory

cards: microSD (SDHC/SDHC/SDXC) up to 256 GB. Processor:

(1) ARM Cortex-A75 (2.0 GHz) + (3) ARM Cortex-A55 (1.8 GHz).

Number of cores: 4. CPU configuration: Unisoc Tiger T310. Internal

clock frequency: 26 MHz. SIM card support: micro-SIM. Communication

standards: 2G (Band 3/8), 3G (Band 1/8), 4G (Band 1/3/7/8/20/38).

Front camera: 2.0 MP. Main camera: 5.0 MP. GPS module: yes.

Built-in microphone: yes. Built-in speakers: yes. Battery: LiPo (built-in).

Battery capacity: 5,000 mAh, 3.7 V. Power supply: power adapter

(input 100–240 V, 50–60 Hz, 0.3 A (AC), output 5 V / 2.0 A (DC)).

Wi-Fi: IEEE 802.11 a/b/g/n/ac (2.4 GHz + 5 GHz), 14 dBm. ВT:

version 5.0, 2402–2462 MHz, 5 dBm. Operating conditions:

temperature −10...+45 °C, up to 80 % RH (without condensation).

Storage conditions: temperature −10...+45 °C, up to 80 % RH.

Colour: grey. Case material: ABS plastic, PC. Size (L×W×H):

124

mm. Weight: 3

Functions

A tablet is a multimedia device for playing various content (audio

and video files, music, audiobooks, movies, etc.)

Scope of supply

TDT45

8_4G_E tablet, power adapter with USB Type

C cable

(1.5

m), screen protector, screen cleaning cloth,

quick start guide

Warranty

year

Service life

year

Operating instructions

Before you use the device, read the information in the "Safe use guidelines" section.

Charging the battery

Before using the device for the first time, charge the battery by connecting the

supplied power adapter to the power connector (see item 1 of the figure above) on

the tablet.

Inserting SIM card

Note. Do not insert or remove the SIM card while the device is on.

1. Switch off the device and open the cover to the SIM and SD cards access.

2. Insert the SIM card into the slot in the correct position, as illustrated in the figure

on the device. Push until you hear a click.

3. Close the cover and turn on the device.

Note. Insert the SD card in the same way.
