Viewsonic VA1703WB [16/21] Other information
![Viewsonic VA1703WB [16/21] Other information](/views2/1102810/page16/bg10.png)
ViewSonic VA1703w/VA1703wb 14
Other Information
Specifications
1
Macintosh computers older than G3 require a ViewSonic
®
Macintosh adapter. To order an adapter, contact
ViewSonic.
LCD Type
Color Filter
Glass Surface
17” (full 17" wide viewable diagonal area),
TFT (Thin Film Transistor), WXGA+,
0.255 mm pixel pitch
RGB vertical stripe
Anti-Glare
Input Signal Video
Sync
RGB analog (0.7/1.0 Vp-p, 75 ohms)
Separate Sync,
f
h
:24-82 kHz, f
v
:50-75 Hz
Compatibility PC
Macintosh
1
Up to 1440 x 900 Non-interlaced
Power Macintosh up to 1440 x 900
Resolution Recommended
and supported
1440 x 900 @ 60, 75 Hz
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 72, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50/60 Hz (auto switch)
Display area Full Scan 367.2 mm (H) x 229.5 mm (V)
14.45" (H) x 9.04" (V)
Operating
conditions
Temperature
Humidity
Altitude
41° F to + 95° F (5° C to + 35° C)
20% to 80% (non-condensing)
To 10,900 feet
Storage
conditions
Temperature
Humidity
Altitude
-4° F to + 131° F (-20° C to + 55° C)
20% to 85% (non-condensing)
To 40,000 feet
Dimensions Physical 406.7 mm (W) x 374.9 mm (H) x 210 mm (D)
15.98" (W) x 14.75" (H) x 8.27" (D)
Weight Physical 7.05 lb (3.2 kg)
Regulations BSMI, CCC, PSB, C-Tick, CE, GS, VCCI,
Ergo, Gost-R/Hygienic, SASO, MPR II,
UL/cUL, FCC-B, ICES-B, NOM, TUV-S, E
NERGY STAR
®
Power saving
modes
On
Off
Normal (green LED)
<1W (orange LED)
Preset Timing Mode (pre-adjusted to VESA
®
1440 x 900 @ 60 Hz)
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in
permanent damage to the LCD display.
