ViewSonic VA903m/VA903b/VA903mb 14
Other Information
Specifications
1
Macintosh computers older than G3 require a ViewSonic
®
Macintosh adapter. To order an adapter, contact
ViewSonic.
LCD Type
Color Filter
Glass Surface
19” (full 19" viewable diagonal area),
TFT (Thin Film Transistor), Active Matrix SXGA LCD,
0.294 mm pixel pitch
RGB vertical stripe
Anti-Glare
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
Separate Sync,
f
h
:24-82 kHz, f
v
:50-75 Hz
Compatibility PC
Macintosh
1
Up to 1280 x 1024 Non-interlaced
Power Macintosh up to 1280 x 1024
Resolution Recommended
and supported
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 72, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50/60 Hz (auto switch)
Display area Full Scan 376.32 mm (H) x 301.056 mm (V)
14.82" (H) x 11.85" (V)
Operating
conditions
Temperature
Humidity
Altitude
32° F to + 104° F (0° C to + 40° C)
20% to 90% (non-condensing)
To 10,000 feet
Storage
conditions
Temperature
Humidity
Altitude
-4° F to + 140° F (-20° C to + 60° C)
5% to 90% (non-condensing)
To 40,000 feet
Dimensions Physical 416 mm (W) x 428 mm (H) x 210 mm (D)
16.38" (W) x 16.85" (H) x 8.27" (D)
Weight Physical 10.9 lb (4.9 kg)
Regulations BSMI, CCC, PSB, C-Tick, CE, GS, Ergo
Gost-R/Hygienic, SASO, TCO'03, UL/cUL, FCC-B, ICES-B,
NOM, TUV-S/IRAM/UL-AR S Mark, E
NERGY STAR
®
Power saving
modes
On
Off
35 W (Typical) (green LED)
<1W
Preset Timing Mode (pre-adjusted to VESA
®
1280 x 1024 @ 60 Hz)
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in
permanent damage to the LCD display.
