Tablet
А8
6
©
Topdevice
EN General info
Specifications
11
(Go edition). Multi-touch: yes. RAM: 2 GB. Built-in memory: 32 GB.
Supports memory cards: microSD (SDHC/SDHC/SDXC) up to 256 GB.
Processor: (1) ARM Cortex-A75 (2.0 GHz) + (3) ARM Cortex-A55
(1.8 GHz). Number of cores: 4. CPU configuration: Unisoc Tiger
T310. Internal clock frequency: 26 MHz. SIM card support: micro-
SIM. Communication standards: 2G (850/900/1800/1900 MHz), 3G
(900/2100 MHz), 4G (Band 1/3/7/8/20/38). Front camera: 0.3 MP.
Main camera: 2.0 MP. GPS module: yes. Built-in microphone: yes.
Built-in speakers: yes. Battery: Li-ion (built-in). Battery capacity:
4,000 mAh. Power supply: power adapter (input 100–240 V, 50–
60 Hz, 0.3 A (AC), output 5 V / 2.0 A (DC)). Wi-Fi: IEEE 802.11 a/b/g/n/ac
(2.4 GHz + 5 GHz), 15 dBm. ВT: version 5.0, 2402–2480 MHz,
10 dBm. Operating conditions: temperature 0...+45 °C, up to 80 %
RH (without condensation). Storage conditions: temperature
−10...+55 °C, up to 80 % RH. Colour: grey. Case material: ABS
plastic, PC. Size (L×W×H): 209.2×125.6×9.8 mm. Weight: 350 g
Functions
A tablet is a multimedia device for playing various content (audio
and video files, music, audiobooks, movies, etc.)
Scope of
supply
TDT4518_4G_E tablet, power adapter with USB Type
-
C cable
(1.5
m), screen protector, screen cleaning cloth, quick start guide
Warranty
2
year
s
Service life
2
year
s
Operating instructions
Before you use the device, read the information in the "Safe use guidelines" section.
Charging the battery
Before using the device for the first time, charge the battery by connecting the
supplied power adapter to the power connector (see item 1 of the figure above) on
the tablet.
Inserting SIM card
Note. Do not insert or remove the SIM card while the device is on.
1. Switch off the device and open the cover to the SIM and SD cards access.
2. Insert the SIM card into the slot in the correct position, as illustrated in the figure
on the device. Push until you hear a click.
3. Close the cover and turn on the device.
Note. Insert the SD card in the same way.
