Viewsonic VA2014WM [17/25] Other information
![Viewsonic VA2014w [17/25] Other information](/views2/1102980/page17/bg11.png)
ViewSonic VA2014w/VA2014wm 15
Other Information
Specifications
1
Macintosh computers older than G3 require a ViewSonic
®
Macintosh adapter. To order an adapter, contact
ViewSonic.
LCD Type
Display Size
Color Filter
Glass Surface
TFT (Thin Film Transistor), Active Matrix 1600 x 900 LCD,
0.276 mm (H) x 0.277 mm (V) pixel pitch
Metric: 51cm
Imperial: 20” (20” viewable)
RGB vertical stripe
Anti-Glare
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
Separate Sync
f
h
:24-82 kHz, f
v
:50-75 Hz
Compatibility PC
Macintosh
1
Up to 1600 x 900 Non-interlaced
Power Macintosh up to 1600 x 900
Resolution Recommended
and supported
1600 x 900 @ 60 Hz
1440 x 900 @ 60 Hz
1400 x 1050 @ 60 Hz
1360 x 768 @ 60 Hz
1280 x 1024 @ 60 Hz
1024 x 768 @ 60, 70, 72, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50/60 Hz (auto switch)
Display area Full Scan 442.8 mm (H) x 249.1 mm (V)
17.43" (H) x 9.8" (V)
Operating
conditions
Temperature
Humidity
Altitude
+32° F to +104° F (0° C to +40° C)
20% to 90% (non-condensing)
To 10,000 feet
Storage
conditions
Temperature
Humidity
Altitude
-4° F to +140° F (-20° C to +60° C)
5% to 90% (non-condensing)
To 40,000 feet
Dimensions Physical 481.2 mm (W) x 368.6 mm (H) x 200 mm (D)
18.94" (W) x 14.51" (H) x 7.87" (D)
Weight Physical 8.8 lb (4 kg)
Regulations BSMI, CCC, PSB, C-Tick, KC, CE, Ergo,
Gost-R/Hygienic, Ukraine, SASO, UL/cUL, NOM,
FCC-B, ICES-B, TUV-S/UL-AR S Mark, E
NERGY STAR
®
Power saving
modes
On
Off
25W (Typical) (VA2014w) (blue LED)
30W (Typical) (VA2014wm) (blue LED)
<0.5W
Preset Timing Mode (pre-adjusted to VESA
®
1600 x 900 @ 60 Hz)
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in
permanent damage to the LCD display.
