9 INSTRUCTION MANUAL

Assembly of a vacuum cleaner

• Connect the flexible hose supplied with the hose connection hole

on the vacuum cleaner housing; press the hose slightly towards

the housing until you hear a characteristic click indicating that the

hose is fixed. To remove the hose, press the retainer and pull the

hose towards you.

• Connect the steel telescopic tube to the vacuum cleaner hose. Press the clamp on the pipe and

pull it to the desired length. Release the latch, the tube will be fixed.

• Attach one of the attachments supplied in the kit.

NOTE:

There is a manual air flow regulator on the handle of the flexible hose, which allows to reduce

the suction force for a short time (for example, when cleaning curtains).

USING A VACUUM CLEANER

• Assemble the vacuum cleaner as described above. Select the nozzle according to the intended

coating.

• Pull the power cord to the desired length without exceeding the red mark. Connect the vacuum

cleaner to the mains with the appropriate parameters. Make sure that the power cable does not

hang over the sharp edges of the furniture.

• Press the power key and the vacuum cleaner will start working. To temporarily reduce the

suction power, use the air flow regulator on the flexible hose.

• For ease of movement, the vacuum cleaner is equipped with two wheels and a rotary roller; it is

enough to pull the flexible hose without exerting additional effort.

• There is a handle in the upper part of the vacuum cleaner housing for carrying the vacuum

cleaner.

• After the end of operation of the device, disconnect it from the power supply. Remove the

nozzles and the flexible hose. Press the automatic winding key to hide the cord.

NOTE:

• During operation, some parts of the housing may heat up, which is not a malfunction.

• The device is equipped with a thermostat that prevents overheating. If the vacuum cleaner

turns off spontaneously during prolonged operation, it is necessary to disconnect the device

from the mains and let it cool down for an hour. After cooling down, the vacuum cleaner can

be used normally.

CARE AND CLEANING OF THE VACUUM CLEANER

Cleaning the dust collection container

• Disconnect the device from the mains. Disconnect the flexible hose from the vacuum cleaner

housing by pressing the clamps on the side of the hose.
