ENG

User Manual

SPS-512

2. PACKAGE CONTENTS

•Speakers — 2 pcs

•Operation manual — 1 pc

•Warranty card — 1 pc

3. SAFETY PRECAUTIONS

•Do not open the MSS and do not perform repairs by yourself. Service and repairs

should be performed only by qualied specialists at authorized service centers. The list of

authorized service centers is on www.sven.

•Do not allow the circuit of wires (including the grounded ones) between the speakers, on

the power amplier or the ground, for it causes damage to the power amplier output stage.

•Make sure that foreign objects do not get inside the holes of the MSS.

•Protect the MSS from high humidity, water and dust.

•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not

expose it to direct sunlight.

•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

•If the MSS does not operate, unplug it and address your dealer.

4. TECHNICAL DESCRIPTION

SPS-512 Multimedia Speaker Systems 2.0 (MSS) are designed to play music and sound

games, movies etc. MSS has built-in bridge amplier, acoustic and signal cable due to which

it can be connected to virtually any audio source TV, PC, etc. MSS is connected to power

supply via USB-port of a PC, laptop or 5V DC power supply with a cable USB.

MSS special features

•Power supply via USB-port of a PC, laptop or 5V DC power supply

•Dynamic synchronous RGB backlight

•Switchable backlight

•Volume control on the cable

•Audio sources stereo audio input

•MDF speaker cabinets

5. PREPARATION AND OPERATION

Speaker placement

•Place the speakers symmetrically to the listener at least one meter away.

•Place MSS far away from monitors and TV sets, as insignicant image distortion in these

super-sensitive devices is possible.

MSS Connecting

•Before connecting, make sure that MSS is unplugged. Connect signal cable mini-jack 3,5 mm

built-in speaker to audio output of the sound source, for example computer, as shown in

the diagram below.

•Connect USB-connector to USB-port of PC (laptop or 5V DC power supply) via built-in

USB-cable.

•Set volume level to minimum by turning VOLUME +/- control wheel on the cable

counterclockwise until it stops.

•Turn on PC power supply.

•Adjust volume level by turning VOLUME +/- control wheel.

•If necessary, you can turn on / off lights, using a switch on the cable.

Notes:

•After nishing operation with MSS, mind to turn off the USB-cable from the PC, laptop

USB port or 5V DC power supply.
