Grundig DSB 2100 [15/43] Connection __________________________

Grundig DSB 2100 [15/43] Connection __________________________

15

ENGLISH

CONNECTION __________________________

Dolby Atmos

®

Dolby Atmos gives you amazing experience you

have never before by overhead sound, and all

the richness, clarity, and power of Dolby sound.

For using Dolby Atmos

®

1. Dolby Atmos

®

is available only in HDMI mode.

For the details of the connection, please refer

to “HDMI CONNECTION”.

To use Dolby Atmos

®

in HDMI 1 and HDMI 2

mode, your TV has to support Dolby Atmos

®

.

2. Make sure that “No Encoding“ is selected for

bitstream in the audio output of the connec-

ted external device (e.g. Blu-ray DVD player,

TV etc.).

3. While entering Dolby Atmos / Dolby Digital /

PCM format, the soundbar will show DOLBY

ATMOS / DOLBY AUDIO / PCM AUDIO.

Tips:

• The full Dolby Atmos experience is only availa-

ble when the Soundbar is connected to the

source via a HDMI 2.0 cable.

• The Soundbar will still function when con-

nected via other methods (such as a Digital

Optical cable) but these are unable to support

all of the Dolby features. Given this, our recom-

mendation is to connect via HDMI, in order to

ensure full Dolby support.

Demo mode:

In standby mode, Long press (VOL +) and (VOL

-) button on soundbar at the same time. The

soundbar will power on and demo sound can be

activated. The demo sound will play around 20

seconds.

Note:

1. When demo sound be activated, you can press

button to mute it.

2. If you want to listen the demo sound longer,

you can press to repeat the demo sound.

3. Press (VOL +) or (VOL -) to increase or decre-

ase the demo sound volume level.

4. Press button to exit demo mode and the

unit will go to standby mode.

HDMI Connection

Some 4K HDR TVs require the HDMI input or pic-

ture settings to be set for HDR content reception.

For further setup details on HDR display, please

refer to the instruction manual of your TV.

Using HDMI to connect the soundbar, AV equip-

ment and TV:

Method 1: ARC (Audio Return Channel)

The ARC (Audio Return Channel) function allows

you to send audio from your ARC- compliant TV

to your sound bar through a single HDMI con-

nection. To enjoy the ARC function, please ensu-

re your TV is both HDMI-CEC and ARC compliant

and set up accordingly. When correctly set up,

you can use your TV remote control to adjust the

volume output (VOL +/- and MUTE) of the sound

bar.

• Connect the HDMI cable ( included ) from

unit's HDMI (ARC) socket to the HDMI (ARC)

socket on your ARC compliant TV. Then press

the remote control to select HDMI ARC.

Tips:

• Your TV must support the HDMI-CEC and ARC

function. HDMI-CEC and ARC must be set to

On.

• The setting method of HDMI-CEC and ARC

may differ depending on the TV. For de-

tails about ARC function, please refer to the

owner’s manual.

• Only HDMI 1.4 or higher version cable can

support the ARC function.

• Your TV digital sound output S/PDIF mode set-

ting must be PCM or Dolby Digital

• Connection could be failed due to using so-

ckets other than HDMI ARC while using the

ARC function. Make sure the Soundbar is con-
