10
ENGLISH
CONNECTIONS ________________________________
Bluetooth Connection
The bluetooth pairing model of the unit
is Grundig PartyHit, press " " button
on the top panel to enter the Bluetooth
mode, the LED indicator on the front pa-
nel will flash blue, use your mobile phone
to search the bluetooth signal of the unit,
then input the password 0000 if neces-
sary, the unit will synchronize to play
songs on your mobile phone while you
hear a prompt tone of the unit means to
connect successfully, the LED indicator
on the front panel will keep solid blue for
3 seconds and go out. Disconnect the
bluetooth on the mobile phone to switch
off the bluetooth connect.
The bluetooth is connected to your au-
dio device successfully for the first time,
power off the player then power on, the
speaker will reconnected automatically.
press [PLAY/PAUSE] to resume the play-
back.
C
• Bluetooth connection range
in 10 meters.
• The model PartyHit in your
device was not deleted.
• In bluetooth mode,[PLAY/
PAUSE], [VOLUME] etc. are
also active.
TWS Connection
• This TWS (TRUE WIRELESS STEREO)
bluetooth connection only use between
the same two speakers.
• Power on both speakers, press and
hold TWS button on both speakers, the
LED indicator on the front panel on the
both speakers flash green, wait a few
seconds to pair automatically, once
connected successfully, the LED indi-
cator on the front panel on the Master
speaker keep solid green for 3 seconds
and go out, after connected two spea-
kers, the master and slave will not be
distinguished temporarily.
• Enable your bluetooth device and make
sure it is in searching mode.
• Select “Grundig PartyHit” from the list
of discovered devices and connect to it,
the one successfully connected to your
bluetooth device will be used as the
master, the other speaker is configured
as the slave.
• The master speaker will act as the left
channel during TWS and will receive the
bluetooth signal, the other speaker will
act as the right channel to play music.
• Press and hold TWS button to dis-
connect the HOST and the SLAVE spe-
aker connection in TWS connection
mode.
USB Connection
Insert a USB drive in USB SLOT on the rear
panel of the unit, the LED indicator on the
front panel will show red for 3 seconds
and go out, the unit will switch to the USB
mode automatically, the unit will play MP3
track in the connected USB drive .
AUX IN Connection
This unit has a audio input terminal. You
can input the analogue stereo audio sig-
nals from extra devices such as VCD, CD,
VCR,MP3 player, etc.
Use the audio cable with a 3.5mm
connector to connect the input terminal
AUX IN on the rear panel of the unit,the
LED indicator on the front panel will show
yellow for 3 seconds and go out, the unit
switches to the AUX IN mode automati-
cally.
