1. The water heater is connected to a water
supply network with a pressure of at least
0.02 MPa, maximum 0.7 MPa
2. To connect the water heater to the water
supply, pipes with a diameter of G1/2 are
used.
3. When connecting pipes, use rubber seals
on the threaded pipe ends to prevent
leakage.
4. Screw the safety valve onto the inlet
pipe, marked in blue and with a sign of
the direction of water ow, so that the
water ow matches the direction of the
arrow on the valve body. On the pressure
relief hole of the safety valve, put a drain
pipe to drain water (it may appear when
heated) into the sewer.
5. The safety valve is installed on the cold
water pipe (marked with a blue ring).
(maximum pressure 0.7 MPa / 7.0 Bar). If
the water pressure in the line exceeds 6
Bar, a pressure reducing valve should be
installed.
6. Connect the water heater with the valve
mounted to the water supply network -
install a shut-o valve at the water supply
point.
7. Connect the desired number of
consumption points to the outlet marked
in red.
8. Open the shut-o valve and one of the
collapsible valves. After lling the tank, as
evidenced by the outow of water from
the collapsible tap, close the collapsible
tap and check the tightness of all
connections.
Water supply connection
Please use the accessories provided by the
manufacturer to install the water heater.
The electric water heater must not be
mounted on the wall before you make
sure that the bracket is securely and rmly
installed. Otherwise, the electric water
heater may fall o the wall, resulting in
damage and even serious injury or injury.
When determining the points for holes
for anchor bolts, a free space between the
bottom of the water heater and the oor
should be at least 0.6 m.
Mounting
1. Determine the points for the bolt
holes (determined according to the
specication of the instrument you have
chosen). Drill two holes of appropriate
depth in the wall using a drill bit that ts
the bolts, install the mounting bracket,
and then hang the electric water heater.
2. Attach the power outlet to the wall. The
socket requirements are as follows: 220-
240V / 10A, single-phase, three-wire. It is
recommended to place the socket on the
right side above the water heater.
The water pressure in the water heater
corresponds to the water pressure in the
water main. If the pressure in the line
exceeds 0.7 MPa, then a pressure reducer
should be installed in front of the water
heater so that the pressure does not
exceed 0.7 MPa.
In places or on a wall where water can
enter, the installation height of the
electrical outlet must be at least 1.8 m.
Attention!
Attention!
Attention!
