Connection

Antenna input

• Connect an external DVB-T/T2 antenna

(cable) connector to the antenna input RF IN.

The signal in the block cable antenna

can fail to contain DVB-T/T2 signal due to the

carrier frequency altered by the cable network

operator.

In order to receive digital air TV signal

use an indoor or outdoor UHF antenna.

Specify the possibility and quality of digital air

signal with your local digital TV service

providers. The absence of a stable TV signal in

your area can-not be a reason for returns or

refunds without an additional test of TV signal

reception in your area.

To increase the reception quality of the

state digital air television in rural areas or at

significant distances from a broadcasting

center we recommend using individual active

outdoor UHF antenna with a high resistance

factor, and placing them at maximum possible

heights.

HDMI-out

• If your TV has an HDMI video input,

connect it to an HDMI output of this unit using

an HDMI cable (included).

Stereo audio output

• Connect the left (white) and right (red)

terminals of the stereo audio output to the

corresponding audio inputs on your TV using

an RCA cable.

Video output

• Connect the yellow composite

video output to the composite video input on

your TV using an RCA cable.
