TEST DISHES IN ACCORDANCE WITH EN 60705
Authorities check the quality and proper operation of the microwave oven with these dishes.
In accordance with EN 60705, IEC 60705 or DIN 44547, EN 60350 (2009)
Bringing to readiness and defrosting with microwaves
Cleaning zone Note
Front panel Warm soapy water. Clean with soft cloth, and then wipe dry. Do not use
scrapers.
Indentations on the bottom of the
operational chamber
Damp cloth. Water mustn’t get into the device through the turntable’s drive.
Glass turntable and roller ring Warm soapy water. Make sure the turntable is locked properly.
Glass door Glass cleaner detergent. Clean with a soft cloth. Do not use scrapers.
Seal Warm soapy water. Clean with soft cloth. Do not rub! Do not use scrapers.
Microwave preparation
Dish
Microwave Power (Watts)
cooking time (min)
Notes
Omelet, 750 g. 360 W, 12-17 min + 90 W, 20-25 min
Place the Pyrex mold 20x25 cm on a rotating
stand
Bisquit 600 W, 8-10 min
Place the Pyrex mold 22 cm on a rotating
stand
Meatloaf 600 W, 20-25 min Place the Pyrex mold on a rotating stand
Defrost with microwaves
Dish
Microwave Power (Watts)
cooking time (min)
Notes
Meat 180 W, 807 min + 90 W, 10-15 min Place the Pyrex mold 22 cm on a rotating stand
Defrost with microwaves
Dish
Microwave Power (Watts)
cooking time (min)
Notes
Potato casserole Grill + 360 W, 35-40 min Place the Pyrex mold 22 cm on a rotating stand
Specications
Model MM2006
Power consumption, W max 1150
Rated voltage 220-240 V~ ; 50 Hz
Magnetron frequency 2450 MHz
Microwaves power output, W 700
Inner chamber capacity, L 20
Glass turntable diameter, mm 245
Electric shock protection class I
Storage and transportation temperature -25°C to + 35°C
Operating temperature from +5°C to +35°C
Humidity Requirements 15-75% without condensate
Dimensions (WxLxH), mm
451 х 345 х 256,5
Weight, kg
10,1
*Products should be stored in dry, ventilated warehouses at temperatures below - 25°C.
PRODUCT CERTIFICATION
For information on product certication, see http://www.oursson.com or ask seller for a copy.
Only a qualied specialist from service center must do the repair.
4. Warranty obligations shall not apply to the follow-
ing products, if their replacement is assumed and
is not connected with disassembling products:
• Batteries.
• Cases, straps, cords for carrying, mounting ac-
cessories, tools, documentation that came with
the product.
5. Warranty does not cover defects caused due to
violations of the rules of consumer use, storage or
transportation of the goods, actions of third parties
or force majeure, including but not limited to the
following cases:
• If the defect was a result of careless handling,
used for other purposes, violations of conditions
and rules of operation set forth in the instruc-
tion manual, including as a result of exposure to
high or low temperatures, high humidity or dust,
traces of opening the device independently and/
or self-repair, mismatch state standards for pow-
er grids, getting liquids, insects or other foreign
objects, substances inside the device, as well
as long-term use of the product in extreme op-
erational modes.
• If the defect of the product was a result of un-
authorized attempts to test the product or make
any changes in its construction or software
programs, including repair or maintenance in
unauthorized service centers.
• If the defect of the product was a result of use
of non-standard and/or low quality equipment,
accessories, spare parts, batteries.
• If the defect of the product is associated with
its use in conjunction with additional equipment
(accessories), other than additional equipment
recommended for use with this product. The
manufacturer is not responsible for the qual-
ity of the additional equipment (accessories)
manufactured by third parties, for the quality of
its products together with such equipment, as
well as the quality of the work of the additional
equipment together with the products of other
manufacturers.
6. Product defects detected during the lifetime of
the product are eliminated by the authorized ser-
vice centers (ASC). During the warranty period,
elimination of defects is free of charge with the
presentation of the original certicate of guarantee
SERVICING
OURSSON expresses great appreciation to you for
choosing our products. We have done everything
possible so that this meets your needs, and the qual-
ity corresponds to the best world standards. If your
OURSSON branded product will need maintenance,
please contact one of the authorized service center
(hereinafter - ASC). A complete list of ASC and their
exact addresses can be found on the website www.
oursson.com.
Warranty obligations:
1. Warranty obligations, provided ASC, apply only
to models designed for the production or supply
and sale within the country where the warranty
service is provided, purchased in this country,
certied for compliance with the standards of this
country, and also marked the with ocial marks
of conformity.
2. Warranty obligations operate within the law on
protection of consumer rights and are regulated
by the laws of the country in which they are provid-
ed, and only when the product is used exclusively
for personal, family or household purposes.
Warranty obligations shall not apply to uses of
goods for business purposes or in connection
with the acquisition of goods to meet the needs of
enterprises, institutions and organizations.
3. The manufacturer sets for its products the follow-
ing terms of use and warranty periods:
Product name
Terms of
use, months
Warranty
Period,
months
Microwave ovens
breadmakers, induction hobs
Multicookers, kitchen
processors, electric kettles,
electric grills, hand blenders,
hand mixers, meat grinders,
blenders, toasters, airpots,
toasters, juicers, steamers,
coee makers, choppers,
freezers, refrigerators,
automatic coee machines
Kitchen scales
60 24
