3
APPEARANCE (see fig. A on p. 2) ENG
① – left button; ② – right button; ③ – scroll button with backlight; ④ – resolution increase
button; ⑤ – resolution decrease button; ⑥ – cable; ⑦ – screen; ⑧ – Fn button; ⑨ – Fire
button; ⑩ – Forward button; ⑪ – Back button; ⑫ – operation force switches; ⑬ – sensor.
DESCRIPTION
Purpose: The Lorgar Stricter 579 wired mouse is designed for use in games and other apps
on Windows-based devices.
Design features. 131×72×41 mm, 127 g. Colour: black. ABS plastic (body), PTFE (feet).
Built-in screen, LED backlight, 9 buttons, 2 switches, 1.8 m cable.
Functional features. Connection: USB Type-A. Power supply (input): 5 V / 100 mA (DC), up
to 0.5 W. Sensor: optical. Resolution: up to 12,000 dpi (1600 dpi by default). Response rate:
125–1000 Hz (default is 1000 Hz). Acceleration: up to 30 g. Buttons ① and ② lifespan:
50M presses. 9 programmable buttons. Adjustable operating force for buttons ① and ②.
OLED screen: 96×39 pixels. Operating conditions: temperature 0…+40 °C, up to 85 % RH
(non-condensing). Storage conditions: temperature −15…+60 °C, up to 85 % RH
(non-condensing).
Scope of supply: LRG-GMS579 mouse, quick start guide.
SAFE USE GUIDELINES
Do not expose the mouse to high temperatures (from heaters or direct sunlight) and high
humidity, avoid contact of dust and liquids with the device. Clean the device only after
unplugging it from the power supply, with a dry or slightly damp cloth only. Do not use any
washing or cleaning agents. Do not drop the mouse, disassemble it or repair it yourself.
MOUSE SETTING AND OPERATION
Connection. See fig. B on p. 2. When connecting the mouse for the first time, wait until the
standard drivers are installed.
Button functions. By default, the buttons correspond to the functions listed in the
Appearance section.
The opertion force adjustment. Move switch ⑫ towards the cable ⑥ to decrease the
operating force, or towards the sensor ⑬ to increase the operating force of the buttons ①
and ②.
Setting. Mouse settings adjustment via the screen and buttons is described in the full user
manual. Install the Lorgar WP Gameware to configure mouse settings, to program buttons,
to change the screen image, to create macros and to view statistics. The Lorgar WP
Gameware app and full user manual are available for download at lorgar.eu/drivers-and-
manuals.
TROUBLESHOOTING
The mouse is not working. Restart the device to which the mouse is connected. Connect
the USB cable of the mouse to another port. Check if the mouse is in working order by
connecting it to another device.
If the mouse does not work properly, contact customer service (e-mail support@lorgar.eu;
online chat: lorgar.eu; feedback form: lorgar.eu/for-users).
ADDITIONAL INFORMATION
The information provided herein is subject to change without notice to users. Up-to-date
information and detailed product description, connection and operation steps, certificates and
warranty conditions are available in the complete user manual at lorgar.eu/drivers-and-
manuals. Manufacturer: ASBISc Enterprises PLC, Iapetou, 1, Agios Athanasios, 4101
Limassol, Cyprus. Made in China. All trademarks and brand names are the property of their
respective owners.
