EXTERIOR (see fig. A on p. 2) ENG

① – left earphone; ② – right earphone; ③ – mute button; ④ – volume control wheel;

⑤ – USB cable; ⑥ – microphone; ⑦ – LED indicator.

TECHNICAL SPECIFICATIONS

Intended use. The Lorgar Kaya 360 wired headset is a pair of over-the-ear closed-back

headphones with a retractable microphone. The headset is designed to input and output

sound while gaming, making voice calls and working in other applications. Compatible with

Windows, macOS, Linux, PS4, PS5, Xbox One, Xbox Series S/X.

Design features. Adjustable headband and ear cups. Polycarbonate, ABS plastic, polyester;

192×185×88 mm; 312 g. Braided USB cable, 2 m.

Functional features. Volume and microphone control. Connection: wired, to USB Type-A.

Power supply: input 5 V / 50 mA (DC), up to 0.25 W. Microphone: omnidirectional, (−42 ±

3) dB, 100–3000 Hz. Speakers: 40 mm, (125 ± 3) dB, 20–20,000 Hz, 32 ohms, 25 mW.

Operating conditions: 0…+45 °C temp., 45–75 % RH (non-condensing). Storage conditions:

−20...+45 °C temp., 5–75 % RH (non-condensing).

Package contents. LRG-GHS360 headset, quick start guide.

SAFE USE GUIDELINES

To avoid hearing damage, set the volume to minimum before using the headset; do not raise

the volume for long periods of time during use. Do not use the headset while driving a vehicle.

Do not expose the headset to high temperatures (from heaters or direct sunlight) or high

humidity and avoid the ingress of dust and liquids. Clean it only after unplugging from the

power supply and only using a dry or slightly damp cloth. Do not use any washing or cleaning

agents. Do not drop the headset. Do not disassemble or repair the headset yourself. In the

event of a malfunction, contact the service center.

HEADSET OPERATION

1. Connection process. See fig. B on p. 2. On first connection, it may take a few seconds

for the system to detect the headset.

2. Adjustment. Put on the headset and adjust its position (see fig. C on p. 2).

3. Volume and microphone control. See fig. D on p. 2.

TROUBLESHOOTING

The headset is not working. Make sure that the cable is properly connected and not

damaged. Make sure that the headset is selected for recording and outputting audio in the

settings of the device* or application you are using. Check the volume level on the headset

and device*. Check the microphone sensitivity level in the settings of the device* or

application you are using. Check the system settings that may restrict microphone operation.

WARRANTY SERVICE

The warranty period starts from the moment of retail sale. To obtain warranty service, contact

the point of purchase and provide the product with a proof of payment. The warranty period

and service life are 2 years, unless otherwise provided by local law. More information about

use and warranty is available at lorgar.eu/warranty-terms.

ADDITIONAL INFORMATION

The information provided herein is subject to change without notice to users. Up-to-date

information and detailed product description, connection and operation steps, certificates and

warranty conditions are available in the full user manual at lorgar.eu/drivers-and-manuals.

Manufacturer: ASBISc Enterprises PLC, Iapetou, 1, Agios Athanasios, 4101 Limassol,

Cyprus. Made in China. All trademarks and brand names are the property of their respective

owners.

* 'Device' means a computer, laptop or gaming console.
