Sven SRP-100 [5/16] User manual

ENG

User Manual

SRP-100

Radio mode

• In standby mode, press button q to switch to FM mode, the station frequency will

appear on the display and the FM indicator g will light up.

• In FM mode, press and hold button q for 3 seconds - the auto search mode is activated

(stations in the range from 87.5 MHz to 108 MHz), all stations found will be automatically

saved.

• After completing the tuning, you can select the desired station using buttons d and e.

• If no operation is performed for more than 5 seconds during setup, the unit will switch

to the current time display mode.

Searching for stations manually

• Press and hold for 3 seconds button d turns on station search down the range, press

and hold for 3 seconds button e, turn on station search up the range.

• To store the station, press and hold the button SLEEP p for 3 seconds, the display i

will show «P##», press the button d or e to select the station number you want to store.

Press the SLEEP p button to end the manual storage of stations.

Volume control

• Adjust the volume using buttons a and b.

Adjusting the brightness of the LED display

• Press button c to select the desired brightness of the LED display, 4 levels: bright -

medium - dark - off. By default, the brightness level is medium

TECHNICAL SPECIFICATIONS

Parameter, measurement unit Value

Frequency range, Hz 350 – 10 000

Output power (RMS), W: 2

Diffuser diameter, mm Ø 49

Power supply lithium-ion battery,

3.7В/1200 mAh USB/

Rated current, A 0.074

Colour black

Dimensions, mm 157 × 44 × 88

Weight, kg 0.22

Notes:

• Technical specifications given in this table are supplemental information and cannot

giveoccasion to claims.

• Technical specifications and package contents are subject to change without notice due

to the improvement of SVEN production.
