English - 21 -
storage capacity of your TV. After doing this, that
device will only be usable with the TV. Follow the
on-screen instructions and read the information
displayed on the screen before proceeding.
Note: Formatting the connected storage device will erase
all data installed on it. Back up the les that you want to keep
before you proceed with formatting the device.
Delete & format as removable storage: If you did
priorly format your USB storage device as device
storage, it will only be usable with your TV. You
can use this option to format it again in order to
use it with other devices. Before proceeding with
the formatting, you may consider backing up the
data on your device to your TV’s internal storage
or to another USB storage device using the Back
up apps option. Otherwise, some apps may not
work properly after formatting. Follow the on-screen
instructions and read the information displayed on
the screen before proceeding.
Note: Formatting the connected storage device will erase
all data installed on it. Back up the les that you want to keep
before you proceed with formatting the device.
You can also go to the Notications section on the
Home Screen after connecting your USB device to
your TV to see the available options. Highlight the
notication related to your connected USB device
and press OK.
Browse: Opens the Storage menu.
Setup as device storage: Has the same function
-
ality as the Delete & format as device storage
option described above.
Eject: Same as described above.
Home Screen: Customise your Home Screen. Select
channels which will be displayed on the Home Screen,
enable/disable video and audio previews. Organise
apps and games, change their order or get more of
them. Display open source licences.
For some countries, the Home Screen will be or
-
ganised into several tabs and this menu will contain
additional options to customise the content of these
tabs. Highlight Set up and press OK to sign in to a
Google account, so you can browse personalised
recommendations for that account in the Discover
tab on the Home Screen. After signing in, using
the related options in this menu, you can view your
account activity controls and permissions, customise
services and dene content preferences to get better
recommendations.
Store Mode: Highlight Store mode and press OK. A
dialogue will be displayed asking for your conrmation.
Read the description, highlight Continue and press OK
if you want to proceed. Then highlight On to activate
or O to deactivate and press OK. In store mode your
TV’s settings will be congured for store environment
and the supported features will be displayed on the
screen. Once activated, Store Messaging setting
will become available. Set according to your prefer
-
ence. It is recommended not to activate store mode
for home use.
Google Assistant: Highlight On and press OK to turn
this feature on or o. Select your active account, view
permissions, select which apps to include in search
results, activate safe search lter and oensive word
blocking, view open source licences.
Chromecast Built-in: Set your remote control noti
-
cation preference. Highlight Let others control your
cast media and press OK. Always, While Casting
and Never options will be available. You can display
open source licences and view version number and
serial number under the About section.
Screen Saver: Set the screensaver options for your
TV. You can choose a screensaver, set wait time for the
screensaver or start the screensaver mode.
Energy Saver: Dene a time after which you want
your TV to turn itself o for energy saving. Set as
Never to disable.
Location: You can allow the use of the wireless
connection to estimate the location, see the recent
location requests and allow or restrict the listed apps
to use your location information.
Usage & Diagnostics: Automatically send usage data
and diagnostic information to Google. Set according
to your preference.
Manufacturer Usage & Diagnostics: If you accept,
your TV will send diagnostic information (such as MAC
address, country, language, software and rmware
versions, bootloader versions and the source of the
TV) and anonymous usage data from your device to
a server located in Ireland. We are not able to identify
you and are only collecting and storing this diagnostic
information and anonymous usage data to ensure your
device operates properly.
Accessibility: Congure Audio Type, Visually Im
-
paired, Captions, Text to Speech settings and/or
turn High Contrast Text on/o. Some of the caption
settings may not be applied.
Audio Type: Set your audio type preference.
Normal, Audio Description, Spoken Subtitle,
Hearing Impaired, and Audio Description and
Spoken Subtitle options are available.
Visually Impaired: Set the Audio Type as Au
-
dio Description to enable this option. Digital TV
channels can broadcast special audio commen-
tary describing on-screen action, body language,
expressions and movements for people with visual
disabilities.
Speaker: Turn this option on if you want to hear
the audio commentary through the TV speakers.
