Morning Machine MM-730 Black [15/17] Technical specifications
![Morning Machine MM-730 Black [15/17] Technical specifications](/views2/2040163/page15/bgf.png)
28 29
Occasional drops of
water/Coffee out of the
Coffee Outlet/ Water
By-pass Outlet.
The heater is being
kept warm.
This is normal behaviour
and not a defect.
Coffee comes out in drips
from the Coffee Outlet or
drips back into the Used
Capsule Container.
The ground coee inside
the capsule might be too
fine for water to pass.
Some roasters are grinding
finer for coffee capsules.
This is acceptable.
Dripping is acceptable
at the Coffee Outlet,
as long as there is no
backpressure and causing
leakage into the Used
Capsule Bin.
Select a recipe for light
roasted coffee or finely
ground coffee capsules
via the Morning app.
The pump is running
but no water/coffee is
coming out.
There may be air
bubbles present in the
water passageway in
the Machine.
On your Machine, make
sure your water tank is full
and that there is no capsule
in the Machine chamber.
Then press and hold the
back button to trigger the
Machine to purge water.
Repeat this process until
water comes out from the
coffee spout.
PROBLEM CAUSE SOLUTION
For other issues, please visit www.drinkmorning.com
or get in touch via hello@drinkmorning.com.
Technical Specifications
Size & Weight
40.2cm (L)
×
10.2cm (W)
×
25.5cm (H), 4.5kg
Adjustable Cup Height 15cm (with drip tray), 25cm (without drip tray)
Water Tank Capacity 850ml
Used Capsule Bin Capacity 8-10 capsules
OLED Screen 1.44 inches
OLED Interface
128
×
32 Display
Buttons and Interactions 2 Capacitive Buttons
Rotatable Dial Selection Wheel
Electricity AC220-240V 50-60Hz 1200-1300W;
AC120V 60Hz 1250W
Pump 20 MPa, 120V, 60Hz or 230V, 50Hz
Max Pressure 20 bar
Pressure Control 3 stages, 7 levels
Output Control 1g steps 1g~250g
Temperature Control 75°C-98°C, in 1°C increments
Connectivity Wi-Fi & Bluetooth
Capsule Compatibility Nespresso® OriginalLine capsules and third-party
compatible capsules
Mobile App Works with iOS devices running version 10.0 and later,
and Android devices running version 5.0 and later.
