AORUS 17H (2023) BXF-74US554SH [4/153] Aorus notebook tour

English

004

2. AORUS Notebook Tour

DCIN

8 9 10 11

DCIN

1 Microphone 8 Ethernet Port (LAN)

2 Webcam 9 HDMI 2.1 Port



3 Display Panel 10 Mini Display 1.4 Port

4 Power Button 11 USB 3.2 Port (USB Type-A)

5 Light Sensor Area* 12 Audio Combo Jack

6 Keyboard 13 USB 3.2 Port (USB Type-A)

7 Touchpad 14 Thunderbolt 4 Port (USB Type-C)

* The system will adjust the brightness of the screen

automatically according to the ambient light,

beware not to cover this area.

15 Power Input Port (DC)

16 Speaker

IMPORTANT:

● Do not remove the built-in lithium battery.

For any service needs, please contact your local GIGABYTE Authorized Service Center.

● Do not install the Notebook PC on a slant or a place prone to vibrations, or avoid using the Notebook PC in that

location for

a long time.This increases the risk that a malfunction or damage to the product will occur.

● Do not store and use Notebook PC in direct sunlight or the location where temperatures exceed 112°F (45°C)

such

as inside a vehicle.There is a danger of Lithium-ion battery expansion and aging.

● Do not use the Notebook PC in a badly ventilated location such as on bedding, on a pillow or cushion, etc, and

do not use it in a location such as room with floor heating as it may cause the computer to overheat.Take care

that the Notebook PC vents (on the side or the bottom) are not blocked especially in these environments. If the

vents are blocked, it may be dangerous and cause the Notebook PC to overheat.
