4
• Keep the power cord away from sharp edges and hot surfaces.
• Do not pull the cord. Always take the socket. Do not reel the cord around the device housing.
• Never attempt to frame and repair the appliance by yourself. If you meet problems, please contact the nearest customer service center.
• Using accessories or replacement parts that are not recommended or sold by the manufacturer may cause damage to the appliance.
• Always unplug the appliance and let it cool down before cleaning and removing parts. Keep unplugged when not in use.
• To avoid electric shock and fire, do not immerse in water or other liquids. If this occurs, immediately unplug it and contact service center for inspection.
• Do not use the fan under high humidity conditions (e.g. in the rain) to avoid electric shock and combustion.
• Always place the device on flat stable surface.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Do not touch running parts of the fan.
• Keep foreign objects away from running parts and grille
• Do not block air inlets on the motor block.
• Do not use the fan without protective grilles.
ASSEMBLING THE FAN
• The device is supplied dismantled. Before assembling make sure that the part list is complete and that the device has not been damaged during transportation.
• Do not connect the dismantled unit to power supply. To assemble the unit you have to do the following:
• Unscrew four screws from the base (16)
• Place the stand (14) on the base and secure it with four screws.
• Lower the decorative stand cup (15) on the stand from top to bottom.
• Secure the telescopic tube (12) with the stand (16) with a screw to fix the inner tube (13).
• The retainer of the inner tube (13) must be screwed in before installing the motor section.
• Secure the motor (8) securely to the end of the inner tube (12) with a screw.
• Install the rear protective grille (5) on the motor shaft (6) (8) and secure with the rear grill nut (4).
• Install the fan blades (3) on the motor shaft (6) and secure with the retainer (2).
• Attach the front grille (1) to the rear (5) and secure with the rear grille fixing nut.
• In order to change the height of the fan, loosen the screw to secure the inner tube (13), adjust the desired height and tighten the screw.
USING THE DEVICE
• Key for oscillation turning on/off is located on the motor cover. Press the button to turn on oscillation, the fan will start rotating. To stop oscillation pull out the button.
BUTTONS
- On/Speed – Switching on the fan / changing rotation speed;
- Time – Setting timer for switching off the fan;
- Off – Switching off the fan.
- Mode – selecting rotation mode;
REMOTE CONTROL
• Control and selection of working modes can be done by control panel as well as remote control:
- Mode – selecting rotation mode;
- On/Speed – Switching on the fan / changing rotation speed;
- Timer – Setting timer for switching off the fan;
- Off – Switching off the fan.
