21
ENGLISH TECHNICAL PASSPORT
Cooker hood
USE
The hood is designed to be used ei-
ther for exhausting or lter version.
DUCTING VERSION
In this case the fumes are conveyed
outside of the building by means of a
special pipe connected with the con-
nection ring located on top of the hood.
Attention! The exhausting pipe is
not supplied and must be purchased
apart.
Diameter of the exhausting pipe
must be equal to that of the connection
ring.
In the horizontal runs the exhaust-
ing pipe must be slightly slanted (about
10°) and directed upwards to vent the
air easily from the room to the outside.
Attention! If the hood is supplied
with active charcoal lter, then it must
be removed.
Connect the hood and discharge
holes on the walls with a diameter
equivalent to the air outlet (connection
ange).
Using the tubes and discharge holes
on walls with smaller dimensions will
cause a diminution of the suction per-
formance and a drastic increase in noise.
Any responsibility in the matter is
therefore declined.
! Use a duct of the minimum indis-
pensible length.
! Use a duct with as few elbows as
possible (maximum elbow angle:
90°).
! Avoid drastic changes in the duct
cross-section.
! Use a duct as smooth as possible
inside.
! The duct must be made of certied
material.
FILTER VERSION
One active charcoal lter is needed
for this and can be obtained from your
usual retailer.
The lter removes the grease and
smells from the extracted air before
sending it back into the room through
the upper outlet grid.
INSTALLATION
The minimum distance between
the supporting surface for the cooking
equipment on the hob and the lowest
part of the range hood must be not less
than 45cm from electric cookers and
50cm from gas or mixed cookers.
If the instructions for installation for
the gas hob specify a greater distance,
this must be adhered to.
ELECTRICAL CONNECTION
The mains power supply must cor-
respond to the rating indicated on the
plate situated inside the hood. If pro-
vided with a plug connect the hood to a
socket in compliance with current regu-
lations and positioned in an accessible
area, after installation. If it not tted
