GS2200-8/24 User’s Guide 223

CHAPTER 28

PPPoE

28.1 PPPoE Intermediate Agent Overview

This chapter describes how the Switch gives a PPPoE termination server additional information that

the server can use to identify and authenticate a PPPoE client.

A PPPoE Intermediate Agent (PPPoE IA) is deployed between a PPPoE server and PPPoE clients. It

helps the PPPoE server identify and authenticate clients by adding subscriber line specific

information to PPPoE discovery packets from clients on a per-port or per-port-per-VLAN basis

before forwarding them to the PPPoE server.

28.1.1 What You Can Do

•Use the PPPoE screen (Section 28.2 on page 225) to display the main PPPoE screen.

•Use the Intermediate Agent screen (Section 28.3 on page 226) to enable the PPPoE

Intermediate Agent on the Switch.

•Use the PPPoE Per-Port screen (Section 28.3.1 on page 227) to set the port state and configure

PPPoE intermediate agent sub-options on a per-port basis.

•Use the PPPoE Per-Port Per-VLAN screen (Section 28.3.2 on page 228) to configure PPPoE IA

settings that apply to a specific VLAN on a port.

•Use the PPPoE for VLAN screen (Section 28.3.3 on page 230) to enable the PPPoE Intermediate

Agent on a VLAN.

28.1.2 What You Need to Know

Read on for concepts on ARP that can help you configure the screen in this chapter.

28.1.2.1 PPPoE Intermediate Agent Tag Format

If the PPPoE Intermediate Agent is enabled, the Switch adds a vendor-specific tag to PADI (PPPoE

Active Discovery Initialization) and PADR (PPPoE Active Discovery Request) packets from PPPoE

clients. This tag is defined in RFC 2516 and has the following format for this feature.

PPPoE IA

PPPoE Server

PPPoE Client

Table 81 PPPoE Intermediate Agent Vendor-specific Tag Format

Tag_Type

(0x0105)

Tag_Len Value i1 i2
