Chapter 35 Access Control

GS2200-8/24 User’s Guide

264

35.3.1 Configuring SNMP Trap Group

Use the Trap Group screen to specify the types of SNMP traps that should be sent to each SNMP

manager.

Click Management > Access Control > SNMP > Trap Group to view the screen as shown.

Figure 173 Management > Access Control > SNMP > Trap Group (GS2200-24P)

The following table describes the labels in this screen.

Table 106 Management > Access Control > SNMP > Trap Group

LABEL DESCRIPTION

Trap Destination

Select one of your configured trap destination IP addresses. These are the IP addresses of

the SNMP managers. You must first configure a trap destination IP address in the SNMP

Setting screen.

Use the rest of the screen to select which traps the Switch sends to that SNMP manager.

Type Select the categories of SNMP traps that the Switch is to send to the SNMP manager.

Options Select the individual SNMP traps that the Switch is to send to the SNMP station. See SNMP

Traps on page 271 for individual trap descriptions.

The traps are grouped by category. Selecting a category automatically selects all of the

category’s traps. Clear the check boxes for individual traps that you do not want the Switch

to send to the SNMP station. Clearing a category’s check box automatically clears all of the

category’s trap check boxes (the Switch only sends traps from selected categories).

Note: The poe and fanspeed options are only available in the GS2200-8HP and GS2200-

24P.

Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses these

changes if it is turned off or loses power, so use the Save link on the top navigation panel

to save your changes to the non-volatile memory when you are done configuring.

Cancel Click Cancel to begin configuring this screen afresh.
