Chapter 35 Access Control

GS2200-8/24 User’s Guide

271

SNMP v3 and Security

SNMP v3 enhances security for SNMP management. SNMP managers can be required to

authenticate with agents before conducting SNMP management sessions.

Security can be further enhanced by encrypting the SNMP messages sent from the managers.

Encryption protects the contents of the SNMP messages. When the contents of the SNMP messages

are encrypted, only the intended recipients can read them.

Supported MIBs

MIBs let administrators collect statistics and monitor status and performance.

The Switch supports the following MIBs:

• SNMP MIB II (RFC 1213)

• RFC 1157 SNMP v1

• RFC 1493 Bridge MIBs

• RFC 1643 Ethernet MIBs

• RFC 1155 SMI

• RFC 2674 SNMPv2, SNMPv2c

• RFC 1757 RMON

• SNMPv2, SNMPv2c or later version, compliant with RFC 2011 SNMPv2 MIB for IP, RFC 2012

SNMPv2 MIB for TCP, RFC 2013 SNMPv2 MIB for UDP

SNMP Traps

The Switch sends traps to an SNMP manager when an event occurs. The following tables outline the

SNMP traps by category.

An OID (Object ID) that begins with “1.3.6.1.4.1.890.1.5.8” is defined in private MIBs. Otherwise,

it is a standard MIB OID.

The OIDs beginning with “1.3.6.1.4.1.890.1.5.8.55” are specific to the GS2200-24. The OIDs

beginning with “1.3.6.1.4.1.890.1.5.8.56” are specific to the GS2200-24P. The OIDs beginning

with “1.3.6.1.4.1.890.1.5.8.59” are specific to the GS2200-8. The OIDs beginning with

“1.3.6.1.4.1.890.1.5.8.60” are specific to the GS2200-8HP.

Set Allows the manager to set values for object variables within an agent.

Trap Used by the agent to inform the manager of some events.

Table 111 SNMP Commands

COMMAND DESCRIPTION

Table 112 SNMP System Traps

OPTION OBJECT LABEL OBJECT ID DESCRIPTION

coldstart coldStart 1.3.6.1.6.3.1.1.5.1 This trap is sent when the Switch is

turned on.

warmstart warmStart 1.3.6.1.6.3.1.1.5.2 This trap is sent when the Switch restarts.
