GS2200-8/24 User’s Guide 39

CHAPTER 4

The Web Configurator

4.1 Overview

This section introduces the configuration and functions of the web configurator.

The web configurator is an HTML-based management interface that allows easy Switch setup and

management via Internet browser. Use Internet Explorer 6.0 and later, Netscape Navigator 7.0 and

later, Mozilla Firefox 3.0 and later versions. The recommended screen resolution is 1024 by 768

pixels.

In order to use the web configurator you need to allow:

• Web browser pop-up windows from your device. Web pop-up blocking is enabled by default in

Windows XP SP (Service Pack) 2.

• JavaScript (enabled by default).

• Java permissions (enabled by default).

4.2 System Login

1 Start your web browser.

2 Type “http://” and the IP address of the Switch (for example, the default management IP address is

192.168.1.1) in the Location or Address field. Press [ENTER].

3 The login screen appears. The default username is admin and associated default password is

1234. The date and time display as shown if you have not configured a time server nor manually

entered a time and date in the General Setup screen.

Figure 18 Web Configurator: Login

4 Click OK to view the first web configurator screen.
