15
ENGLISH
VACUUM CLEANER ASSEMBLY
Removing and installing side brushes (6)
•
Turn over the vacuum cleaner, align the brush mount-
ing hole with the drive axle and press the center of
the brush until it stops to secure it. To remove the side
brush, take it by two cords and pull upwards.
Attention! The side brushes are different for each side
of the robot. When installing the side brushes, align the
«L» and «R» marks on the side brush with the «L» and «R»
marks on the bottom of the robot body (Fig. 1).
Removing and installing dust bin (21)
and filter appliance (23, 24)
Press the button (16) and remove the water tank (13)
(fig. 4). Grasp the bin lid (22) handle and remove the dust
bin from the water tank (13). Open the lid (22) by pressing
the side latch and take out the primary filter (24) with the
HEPA filter (23). Check the HEPA filter (23) by removing
it from the primary filter frame (24). Assemble filters in
reverse sequence. Install the HEPA filter (23) back into the
primary filter frame (24), and then install the primary filter
into the dust bin lid (22) and close the lid until it clicks.
Install the dust bin (21) into the water tank (13) and then put
the water tank back into the vacuum cleaner body.
Installation of the self-cleaning station
•
Install the self-cleaning station on a flat floor surface
against a wall, the base of the station should be perpen-
dicular to the floor.
•
The free space in front of the self-cleaning station must
be at least 2 meters, and on the sides of the charg-
ing station the free distance must be at least 1 meter
(Fig. 2).
•
Determine the required length of the power cord to the
electrical outlet and wind it carefully without letting it
hang down (fig. 3). The cord storage (30) can be used
to wind the power cord.
Note: Do not install the self-cleaning station near highly
reflective objects, such as near mirrors, otherwise it will
be difficult for the vacuum cleaner to find the charging
station.
BEFORE USING THE VACUUM CLEANER
•
Remove all kinds of power cords, power extension
cords and other similar items from the floor that may
interfere with the movement of the vacuum cleaner.
•
The vacuum cleaner is intended for operation on a
smooth floor or on a carpet with low pile (no more than
1,5 cm). Do not use the vacuum cleaner for cleaning the
floors and carpets with high pile.
•
Make sure that there are no tablecloths, curtains or
other furnishings hanging to the floor along the path of
motion of the vacuum cleaner.
•
The free space under the pieces of furniture should be
at least 11 centimeters, otherwise the vacuum cleaner
will simply get stuck under the furniture.
•
If the distance from the floor to the furniture is at least
11 centimeters, it is necessary to raise the furniture or
provide a barrier to prevent the vacuum cleaner from
getting into such places.
•
Arrange the pieces of furniture for free movement of the
vacuum cleaner, remove foreign objects from the floor.
•
Do not use the vacuum cleaner in rooms with unsteady
furniture, especially if there are fragile interior objects or
burning candles placed on it.
•
Do not place or install foreign objects on the vacuum
cleaner body, also make sure that there are no pets on
the vacuum cleaner body.
•
Before using the vacuum cleaner, make sure that
there are no bottlenecks along the path of the vacuum
cleaner.
Robot control buttons and indications
1. return home button (1) « »:
Short press: return to the self-cleaning station to charge
the battery.
Long press: enter network connection modes.
Backlight indicator color:
–
White, with a smooth change in brightness: charging.
–
White, steady on: recharging.
–
White, fast or slow flashing: setting network connection
modes.
2. «Start / Pause» button (2) « », turn on / off the
robot:
Long press: power on (off).
Long press: power off (on).
Short press: start/pause (sleep mode).
Backlight indicator color:
–
Blue flashing light: standby/pause.
–
Blue, steady on: cleaning mode.
–
Blue light off: sleep mode.
Remote control
If no button has been pressed, only the time is shown on
the display.
If there is a scheduled task, the «Scheduled» icon will also
be displayed (similarly in other modes).
1. «Start / Pause» button (39) « »
a. In standby mode, press this button and the robot will
start cleaning automatically;
b. In sleep mode, press this button and the robot will enter
into standby mode from sleep mode;
c. In working mode, press this button to enter standby
mode;
e. In charging mode, press this button to enter working
mode.
2. Navigation buttons (to control the movement
of the vacuum cleaner) (38)
- forward button
- turn left button
- turn right button
- backward button
a. In standby mode or in working mode, press these but-
tons to control the movement of the robot;
b. In standby mode, press these buttons to set the time and
date, while setting the current time, or when setting up
scheduled cleaning.
3. Return home button (37) « »
When this button is pressed, the corresponding symbol is
displayed on the remote control display.
Recharging can be carried out in standby or operating
mode.
4. Planning mode enabling button (36) « »
When this button is pressed, the scheduling symbol is
displayed on the remote control display.
