ENGLISH

• In order for the mop to switch out of the standby mode

and start generating steam, simply press the trigger but-

ton (2) or the button (18).

Attention! Do not forcibly remove the water tank (9) dur-

ing operation. Please turn the unit off to avoid contact with

high-temperature steam.

Low water level protection

If the water tank (9) becomes empty, the pump will auto-

matically stop operation in approximately 60 seconds, and

the power/ heating indicator of the button (18) will be flash-

ing green. The pump will resume operation after you fill the

water tank with water.

Manual mode

Press the button (5) and remove the water tank (9) from the

tube holder (8) (pic. 7).

Attention! Do not forcibly remove the water tank (9) dur-

ing operation. Please turn the unit off to avoid contact with

high-temperature steam.

• For cleaning, take either the steam nozzle for manual

cleaning (16) or the hose (17).

• Select the appropriate attachment (12, 13, 14, 21, 22),

install the selected attachment on the steam nozzle

(16) or the hose (17) and turn counterclockwise until a

click sound is heard. This means that the attachment is

installed correctly.

• Insert the steam nozzle (16) or the hose (17) into the

corresponding opening of the water tank (9) until it

clicks (pic. 8).

• The hard-bristled brush (21) and the small nozzle (22)

are used for manual cleaning

• The unit is ready for use.

• To remove the steam nozzle (16) or the hose (17), press

and hold the release button located on the body of the

steam nozzle (16) or the hose (17) and forcefully pull the

nozzle (16) or the hose (17) towards you.

RECOMMENDATIONS ON USING

• Before cleaning the floor, it is recommended to sweep or

vacuum it to remove dust and dirt particles.

• When washing the floor, move the unit in the even back

and forth motion, pushing it away from you and pulling it

back. Move backwards to avoid stepping on the already

washed floor.

• The microfiber cloth (11) collects water when wash-

ing the floor. However, depending on the character-

istics of the floor surface and the set steam intensity,

some moisture may remain on the floor. In this case,

it is recommended to let the floor dry naturally. Drying

can be accelerated by using a fan directed to the

desired area.

• After the cleaning, remove the cloth (11) from the mop

nozzle (10). Then the floor under the mop will not get

soaked from a damp cloth.

• It is recommended to fully change the water in the tank

(9) from time to time to avoid stagnation of water and the

appearance of an extraneous smell.

• The water hardness level is different for every region.

Water can contain hardness salts and other dissolved

minerals. Water evaporates in the boiler and the resi-

due remains.

• If water is soft and does not contain a lot of salts, the

scale flakes will from time to time fall off the boiler

walls and go out with the steam. If water contains a

lot of salts, including the hardness salts, then min-

eral deposits will accumulate in the boiler in a sig-

nificant amount. It will hinder steam generation and

may cause damage. Scale flakes can clog valves and

connections. Therefore, it is recommended to use

demineralized or distilled water to reduce lime scale

and salt deposits.

• Regular jug filters do not remove minerals and salts

from water. Special demineralizing filters are used for

this purpose.

• If you want to use bottled drinking water, find out

its total salinity (usually indicated on the label) and

compare it with indicators for tap water (they can be

found on the water supply company's website, or by

the Internet search). Typically, bottled water salinity is

100-400 mg/l. It may turn out that the water from the

tap has a salinity several times lower, so that the use

of bottled water will increase the formation of scale.

Attention! Scale deposits and salts can be removed from

the boiler only in the service center. This procedure is not

covered by warranty and requires payment.

CLEANING and CARE

• Unplug the unit from the mains and let it cool down.

• Remove the water tank (9) from the tube holder (8).

• Drain the remaining water from the tank (9).

• Wipe the steam mop body with a damp cloth.

• Let the cloth (11) cool down for several minutes

before removing it from the mop nozzle (10).

• You can wash the microfiber cloth in a washing

machine, using a delicate cycle and at temperature

not exceeding 60°C.

• Do not use bleachers, fabric softeners or rinses, so

the cloth can absorb dirt. You can dry the cloth in a

dryer.

• For hand wash, use a mild detergent and dry the cloth

in horizontal position.

Cleaning the water tank

• Perform a routine washing of the water tank. Avoid stag-

nation of water in the tank.

• To remove lime deposits from the water tank, add 1-2

tablespoons of white vinegar into the full water tank,

close the water tank lid and shake the tank well. Then

drain it and wash with clean water.

Note: If you always use distilled water, you don't need to

clean the water tank.

Attention! Perform a test cleaning of a suitable isolated

area after each descaling to make sure that no scale or dirt

is left inside the unit.

STORAGE

Note: After you finish using the mop, remove the water

tank before switching the power off and let the unit oper-

ate for some time until the steam release stops.

• Switch the unit off and unplug it.

• Follow the requirements of the «Cleaning and Care»

section.

• Wind the power cord around the special winding hooks

(3) (fig. 5).

• Place the mop vertically.

Note: the mop can be conveniently stored in a vertical

standby position.

• Keep the steam mop away from children in a dry and

cool place.
