ENGLISH

Chose the place for the vacuum cleaner storage/ battery

charging and fix the wall-mounted holder (25).

•

Make markings on the wall for mounting holes.

•

Drill holes in the wall to the required depth.

•

Insert plastic anchors into the drilled holes, secure the

wall-mounted holder (25) with screws.

Note: before drilling holes in the wall, make sure there are

no electrical wiring or other communications.

Battery Charging

Before using the unit for the first time or after a long period

of inactivity, the battery needs to be charged for 4 hours.

A fully charged battery provides approximately 15 minutes

of continuous vacuum cleaner operation at maximal power

level and about 30 minutes of operation at low power level.

•

Place the vacuum cleaner on the wall-mounted holder

(25) for charging, insert the plug of the connecting cord

of the power supply unit (28) into the battery charg-

ing socket of the vacuum cleaner (11) (fig. 1), plug the

power supply unit (28) into the mains socket, it will light

up and the minimal battery charge level indicator (17)

will start flashing. As it charges, the indicator (17) will

stop flashing and start glowing, and the full battery indi-

cator (18) will flash.

•

When the battery is fully charged, both indicators (17,

18) will glow for 10 minutes. Unplug the power supply

unit (28) from the mains.

Notes:

–

Charge the battery at the temperature from +5°C to

+35°C.

–

If you haven’t used the device for a month or longer,

charge the battery completely before using the vacuum

cleaner.

Attaching the extension pipe and attachments

•

Insert the extension pipe into the air inlet of the vacuum

cleaner until the lock (6) clicks.

•

Choose the attachment you need: the motorized brush

(1), the 2-in-1 crevice nozzle (26), the crevice nozzle

(27) and attach it to the extension pipe.

Note: if necessary, you can attach the motorized brush

(1), the 2-in-1 crevice nozzle (26), the crevice nozzle (27)

to the vacuum cleaner air inlet without the extension pipe.

Motorized brush with LED lighting (1)

Use the motorized brush (1) for cleaning floors and car-

pets with medium and low pile, the brush (1) is perfect for

removing pet hair from carpets. The brush is brought to

rotation by an electric motor, it thoroughly combs out pet

hair and sweep motes out of the carpet pile.

The LED illumination lights up when you switch the vacuum

cleaner on, and it raises visibility in dark places.

Notes:

–

Do not use the motorized brush (1) if the pile length

exceeds 15 mm.

–

Do not run the brush (1) over electric wires.

–

Switch the vacuum cleaner off right after cleaning with

the brush (1).

Crevice nozzle 2-in-1 (26)

The crevice nozzle (26) has 2 options. The crevice nozzle

mode is intended for cleaning of radiators, chinks, corners

and spaces between cushions. Use the brush mode for

cleaning upholstered furniture or the car interior. For this,

press the lock button and move the brush forward.

Crevice nozzle (27)

The nozzle (27) is intended for cleaning radiators, chinks,

corners and spaces between cushions.

Floor wet cleaning attachment (22)

Open the water inlet lid (24), pour the water into

the attachment (22), close the lid (24) tightly and

make sure that the water doesn’t leak from the attach-

ment (22).

Install the attachment (22) on the rear side of the brush

(1) (fig. 3). The magnetic mount of the attachment (22)

makes it easy to install and remove.

While cleaning the room, press the water supply button

(23) with your foot, do not allow large drops of water to

appear on the floor.

After you finish, remove the attachment (22), open the lid

(24) and pour out the water, clean the working surface of

the attachment (22) from dust and garbage.

USING THE VACUUM CLEANER

Attention! Switch the vacuum cleaner on only with the

dust bin and the filters (19, 21) installed in the dust bin.

Be sure to check the correct assembly and installation of

the dust container.

Use the wall-mounted holder (25) for easy storing of the

vacuum cleaner.

•

During the operation or when carrying the vacuum

cleaner hold the unit by the handle (10).

•

Before using the vacuum cleaner, press on the brush

(1) to delink it with the latch (2).

•

To switch the vacuum cleaner on, press the on/off but-

ton (9) (fig. 2), the vacuum cleaner will switch on on

high power level, and the maximal suction power indi-

cator (16) will light up.

•

During the vacuum cleaner operation you can select

the vacuum cleaner suction power modes by press-

ing the button (8) (fig. 2). The vacuum cleaner has two

operation modes:

–

at low power level, the indicator (16) doesn’t glow,

the operating time is approximately 30 minutes.

–

at maximal power, the indicator (16) glows, a

charged battery provides approximately 15 minutes

of continuous vacuum cleaner operation.

•

For easy cleaning under furniture, you can release

the curve mechanism of the extension pipe by pull-

ing the lock (5) upwards and select the desired angle

of the extension pipe. To return the extension pipe to

its original position, straighten the pipe until the lock

(5) clicks.

•

After the operation switch the vacuum cleaner off by

pressing the on/off button (9).

•

Use the handle (10) for carrying the vacuum cleaner.

CLEANING AND CARE

Attention! Provide that the dust bin, the mesh filter (21)

and the inlet filter (19) are always clean, because the

overall performance of the vacuum cleaner depends

on it.

Remove garbage and dust from the dust bin after each

usage of the vacuum cleaner and clean the mesh filter

(21) and the inlet filter (19) regularly.

Removing dust and garbage from the dust bin (fig. 4)

•

If during cleaning the dust bin becomes full, remove

dust and garbage from it.
