ENGLISH

•

For easy cleaning it is recommended to remove the

extension pipe by pressing on the lock (6).

•

Position the lid (14) above the garbage bin and press the

lock button (15), the lid (14) will open, remove dust and

debris, close the lid (14) until the lock (15) clicks, install

the extension pipe and continue cleaning the room.

Cleaning the dust bin

•

Press on the dust bin lock (20) and remove the dust

bin (fig. 5).

•

Remove the inlet filter (19) (fig. 6).

•

Remove the mesh filter (21) (fig. 7).

•

Clean the mesh filter (21) (fig. 8).

•

Wash the inlet filter under a warm water jet (fig. 9) and

dry it thoroughly, wash and dry the flask (13) and the

mesh filter (21).

•

Assemble the dust bin, install the mesh filter (21) in the

flask (13), install the inlet filter (19) (fig. 10).

•

Install the assembled dust bin back to its place until the

lock (20) clicking, make sure that the dust bin is fixed

properly (fig. 11).

Notes:

–

Do not use heating units, including the hairdryer, to dry

the removable parts.

–

Before assembling the dust bin and installing it to its

place make sure that all removable parts are clean

and dry.

Cleaning the motorized brush with LED lighting (1)

Keep the brush (1) clean; as it becomes dirty, disassemble

the brush (1) and clean the rotating brush.

•

Remove the brush (1) from the extension pipe by press-

ing the lock (3).

•

Move the lock of the rotating brush (fig. 12).

•

Take out the rotating brush (fig. 13) and remove threads

and hairs wound up around it.

•

Clean the inner and outer surface of the brush (1) body

from garbage and dust.

Assembling the motorized brush with LED lighting (1)

•

Insert the rotating brush into the body (fig. 14).

•

Fix the rotating brush by pressing the lock to the left

until bumping (fig. 15).

•

Make sure that the rotating brush is fixed properly.

Cleaning the vacuum cleaner body

•

Wipe the vacuum cleaner body (12) with a soft, slightly

damp cloth and then wipe it dry.

•

Do not immerse the vacuum cleaner body (12), the

brush (1) and the power supply unit (28) into water or

other liquids. Make sure that no liquid gets inside the

vacuum cleaner body (12) and the brush (1).

•

Do not use solvents or abrasives for cleaning the vacu-

um cleaner body and the removable parts.

STORAGE

•

Before taking the vacuum cleaner away for storage,

clean the vacuum cleaner body (12), the dust bin and

the brush (1).

•

Keep the vacuum cleaner and the attachments (26, 27)

on the wall-mounted holder, in a dry cool place away

from children and disabled persons.

DELIVERY SET

Vacuum cleaner (with the dust bin installed) – 1 pc.

Extension pipe – 1 pc.

Motorized brush with LED lighting – 1 pc.

Crevice nozzle 2-in-1 – 1 pc.

Crevice nozzle – 1 pc.

Wall-mounted holder of the vacuum

cleaner/attachments – 1 pc.

Power supply unit – 1 pc.

Instruction manual – 1 pc.

Warranty certificate – 1 pc

TECHNICAL SPECIFICATIONS

Vacuum cleaner

Power supply: Rechargeable

battery – Li-Ion 21.6 V 2000 mAh

Nominal power consumption: 150 W

Input voltage: 25 V 0.5 A

Battery charge time: 4 hours

Brush

Power supply: 21,6 W

Nominal power consumption: 10 W

Power adapter

Power supply: 100-240 V ~ 50-60 Hz 0,5 A

Output voltage: 25 V 0,5 A

RECYCLING

For environment protection do not throw out the unit and

the batteries (if included), do not discard the unit and the

batteries with usual household waste after the service life

expiration; apply to specialized centers for further recycling.

The waste generated during the disposal of the unit is

subject to mandatory collection and consequent disposal

in the prescribed manner.

For further information about recycling of this product

apply to a local municipal administration, a disposal ser-

vice or to the shop where you purchased this product.

The manufacturer preserves the right to change design,

structure and specifications not affecting general princi-

ples of the unit operation without a preliminary notification

due to which insignificant differences between the manual

and product may be observed. If the user reveals such dif-

ferences, please report them via e-mail info@coolfort.ru

for receipt of an updated manual.

Unit operating life is not less than 3 years

Guarantee

Details regarding guarantee conditions can be obtained

from the dealer from whom the appliance was purchased.

The bill of sale or receipt must be produced when making

any claim under the terms of this guarantee.

This product conforms to the EMC Directive

2014/30/EU and to the Low Voltage Directive

2014/35/EU.
