ENGLISH

• Place the steamer safety stand (1) on a solid, horizontal

stable surface.

• Do not position the steamer at an angle as shown in fig. 1,

because this will cause air to enter the pump and cut off

the steam supply.

• Remove the protection from the steamer soleplate (3) (if

there is any).

• Wipe the steamer soleplate (3) with a clean soft cloth.

• Place the steamer on the steamer safety stand (1). When

working with the steamer, always use the safety stand

to keep the coating of the steamer soleplate (3) from

mechanical damage for as long as possible.

• The steamer handle (5) is rotary, the direction of rotation

of the handle is shown in fig. 2.

• The steamer handle (5) can be rotated 90 degrees (fig. 3)

or 180 degrees (fig. 4).

• Wipe the steamer body with a soft cloth.

• Make sure that the voltage of the mains corresponds to

the operating voltage of the unit.

• There may be water residue in the tank, this is normal,

as the garment steamer has undergone factory qual-

ity control.

FILLING THE WATER TANK

Note: before filling the water tank with water, make sure that

the unit is unplugged.

• Turn the steamer handle (5) by 180 degrees (fig. 4).

• Lift the cover for water inlet opening (9) (fig. 5).

• Pull the cover (9) aside from the water inlet opening

(fig. 6).

• Pour the water through the inlet into the water tank (4).

• Put the water inlet cover (9) back to its place, turn the

steamer handle (5) to its original position and place the

steamer on the stand (1).

USING THE DEVICE

• Place the steamer on the safety stand (1).

• Make sure that there is enough water in the water tank (4).

• Connect the steamer to the mains.

• Press the steamer control button (6) until a distinctive

click.

• During heating the heating/operation mode indicator (7)

will be flashing red.

• After switching to the operation mode the heating/opera-

tion mode indicator (7) will constantly glow blue. The

operating pump will vibrate and the steam will be gener-

ated. After that the steamer is ready for operation.

• Before using the unit, iron a piece of cloth to clean the

steam ducts of the steamer soleplate. During the first

operation some particles may appear from the steamer

soleplate openings, it is normal and not a malfunction.

• If you slightly press the steamer control button (6), the

vibration from the pump will stop and the steam release

will stop, which will allow you to use the steamer in the

iron mode without steaming.

CLEANING AND CARE

Before cleaning unplug the unit and wait till it cools down

completely. Drain the water from the water tank after

every use.

• Open the lid and drain water from the water tank, then put

the lid back to its place (fig. 5).

Regular cleaning

• Wipe the steamer body with a slightly damp cloth and

then wipe it dry.

• Remove the mineral deposit on the steamer soleplate (3)

with a cloth soaked in vinegar-water solution and then

wipe the soleplate surface with a dry cloth.

• Do not use abrasive substances and any solvents to clean

the steamer body.

STORAGE

• Before you take the unit away for storage, make sure that

the unit has cooled down completely.

• Drain the remaining water from the water tank.

• Clean the unit.

• Place the steamer on the safety stand (1).

• Keep the unit in a dry darkened and cool place out of

reach of children and disabled persons.

DELIVERY SET

Garment steamer – 1 pc.

Steamer safety stand – 1 pc.

Beaker – 1 pc.

Warranty certificate – 1 pc.

Instruction manual – 1 pc.

TECHNICAL SPECIFICATIONS

Power supply: 220-240 V ~ 50-60 Hz

Nominal power consumption: 1500 W

Soleplate temperature: 130-160°С

Heating time: 25 seconds

Continuous steam supply up to 32 g/min

Water tank capacity: 90 ml

RECYCLING

For environment protection do not throw out the unit and

the batteries (if included), do not discard the unit and the

batteries with usual household waste after the service

life expiration; apply to specialized centers for further

recycling.

The waste generated during the disposal of the unit is sub-

ject to mandatory collection and consequent disposal in the

prescribed manner.

For further information about recycling of this product apply

to a local municipal administration, a disposal service or to

the shop where you purchased this product.

The manufacturer preserves the right to change design,

structure and specifications not affecting general principles

of the unit operation without a preliminary notification due

to which insignificant differences between the manual and

product may be observed. If the user reveals such differ-

ences, please report them via e-mail info@coolfort.ru for

receipt of an updated manual.

Unit operating life is not less than 3 years

Guarantee

Details regarding guarantee conditions can be obtained

from the dealer from whom the appliance was purchased.

The bill of sale or receipt must be produced when making

any claim under the terms of this guarantee.

This product conforms to the EMC Directive

2014/30/EU and to the Low Voltage Directive

2014/35/EU.
